ConXport . Inverted Metallurgical Microscope

Get a Price/Quote

ConXport . Inverted Metallurgical Microscope Specification

Focus System
Coaxial coarse and fine focusing mechanism.

Spare Parts
Eyepiece, objective, lamp, fuse, dust cover.

View Head
Trinocular, 45 inclined, rotatable 360.

Features
Ergonomic design, anti-fungal optical coatings, long working distance objectives, suitable for metallurgical sample inspection.

Theory
Inverted Metallurgical Microscope for the analysis of metallurgical specimens.

Drawtube
Trinocular head, inclined at 45 for comfortable observation.

Sensor
Not Applicable (optical microscope, no built-in digital sensor).

Resolution
Depends on selected eyepiece and objective, generally up to 1000x magnification optical resolution.

Interface
Mechanical slide holder, trinocular port for camera attachment (optional).

Frame Rate
Depends on digital camera used (not included); up to 30 fps possible.

Focal Distance
Dependent on objective lenses, typically 50mm to 200mm.

Magnification
40x, 100x, 400x, and 1000x (with supplied objectives and eyepieces).

Dimensions
Approx. 350mm x 240mm x 520mm (L x W x H).

Focus Range
Coarse and fine focusing, total travel typically ~15mm.

Eyepieces
Widefield 10x (pair), optional 15x.

Eyepiece Tube
Trinocular, supports observation and camera connection simultaneously.

Illumination
Built-in halogen lamp, 6V/20W, adjustable intensity.

Coarse Adjustment Range
Up to 15mm travel.

Fine Adjustment Range
0.002mm precision fine focus.

Working Stage
Mechanical stage with X-Y movement, size 230mm x 140mm.

Still Image Capture Resolution
Dependent on camera attachment (not native to microscope).

Video Capture Resolution
Dependent on camera attachment (not native to microscope).

Image Format
If camera is attached: JPEG/BMP with digital adapter (optional).

Interpupillary Distance
Adjustable 55-75mm.

Objective Achromatic
Plan achromatic objectives: 4x, 10x, 40x, 100x (oil immersion).

Condenser
Built-in, NA 0.25 or higher, with iris diaphragm.

Light Source
Internal halogen lamp, 6V/20W, intensity variable.

ConXport . Inverted Metallurgical Microscope Trade Information

FOB Port
Delhi

Payment Terms
Telegraphic Transfer (T/T), Paypal, Letter of Credit (L/C)

Supply Ability
15 Per Week

Delivery Time
6-7 Days

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Western Europe, Australia, North America, Eastern Europe, Middle East, Africa, Central America, South America, Asia

Main Domestic Market
All India

Certifications
ISO,CE,FDA,WHO-GMP

About ConXport . Inverted Metallurgical Microscope

Buy the new release ConXport Inverted Metallurgical Microscope, an illustrious model designed for uncompromising analysis in metallography, material science, and laboratory research. Showcasing premier build quality with a sturdy metal frame and anti-rust finish, it guarantees durability and reliability. Precision X-Y graduated stage movement and coaxial focusing optimize sample observation. Its trinocular head allows camera attachment for documentation. This unprecedented microscope delivers variable magnification up to 1000x and features advanced ergonomic design, anti-fungal optics, and heat-resistant safety elements. Buy online now from a leading Indian exporter, supplier, and manufacturer.

Versatile Use and Advanced Features

The ConXport Inverted Metallurgical Microscope is eminently suitable for metallography, industrial inspection, and laboratory research. Its ergonomic trinocular head, long working distance objectives, and multi-filter options make it ideal for demanding analyses. Used as a premier instrument in quality assurance, academic teaching, and detailed failure investigation, it boasts attachments like polarizing slides and DIC. Additional features include a graduated mechanical stage, variable halogen illumination, and anti-fungal optical coatings for superior sample visualization and durability.

Streamlined Payment, Packaging & Sample Policy

Dispatching your ConXport Inverted Metallurgical Microscope is efficient, and each unit is packaged with utmost careincluding a dust cover, spare lamp, and user manualto guarantee safety during transit. Valuation and charges are transparent, with options for advance payments or standard business credit terms. Upon request, sample units are available, subject to nominal charge. Detailed dispatch tracking and after-sales support ensure a seamless acquisition experience, distinguished by prompt customer communication at every stage.

Eyepiece:	WF 10X-22mm
Reticule Eyepiece:	WF 10X-20 mm (Cross Reticule 0.1mm)
Objective:	INFINITY LONG WORKING DISTANCE PLAN Objective , 5X/0.1,10X/0.25, 10X/0.25, 20X/0.4 (S), 50X/0.75 (S) and 100X/1.25 (S, oil)
Head:	Seidentopf Binocular / Trinocular Head Inclined 30, Rotatable 360, Interpupilary Distance: 48-75mm
Nosepiece:	Quintuple
Mechanical Stage:	Stage Size: 226mmX178mm, Travel: 40mmX40mm, stage 16,4 0, Stage micrometer 0.01mm
Focus:	Coaxial Coarse and Fine Focusing Knobs
Illumination:	Halogen 12V/50W -Reflected, Epi-Khler illumination, ISO-CE
Filter:	green, blue, yellow, grey and G glass
Polarizing:	Polarizing and Analyzer Slide
Attachments:	Polarizing , Analyzer Slide and DIC

FAQs of ConXport . Inverted Metallurgical Microscope:

Q: How does the ConXport Inverted Metallurgical Microscope enhance metallographic analysis?

A: The microscopes inverted design, achromatic objectives, and precise X-Y stage facilitate detailed inspection of polished metal specimens, enabling clear visualization and accurate valuation of microstructures and phases.

Q: What is included in the standard package upon dispatching the microscope?

A: Each shipment contains the microscope unit, a dust cover, power cord, spare bulb, fuse, manual, and standard objectives and eyepieces, securely packaged to prevent damage in transit.

Q: When can I request a sample unit, and what charges apply?

A: Sample units are available upon customer request and typically require payment of a nominal charge to cover valuation and shipping. Please consult us for detailed terms.

Q: Where can this microscope be used for optimal performance?

A: It is crafted for use in research laboratories, material science institutions, industrial inspection sites, and educational settings, excelling wherever premium metallurgical analysis is required.

Q: What are the benefits of the trinocular head on this microscope?

A: The trinocular head enables simultaneous visual observation and camera attachment, allowing documentation, image capture, and remote demonstrationsespecially valuable for collaborative environments and record-keeping.

Q: How is the focusing process managed, and what is its precision?

A: Focusing utilizes a coaxial mechanism with both coarse and fine adjustments. Fine focus precision reaches 0.002mm, ensuring clear, accurate imaging of metallurgical and material science samples.
