ConXport Upright Polarizing Microscope PQR-500S

Send Inquiry

Request To Call Back

ConXport Upright Polarizing Microscope PQR-500S

Get a Price/Quote

ConXport Upright Polarizing Microscope PQR-500S Specification

View Head
Trinocular, 360 rotatable, inclined at 30.

Features
360 rotating stage with vernier, analyzer and polarizer, Bertrand lens for conoscopic and orthoscopic observations, strain-free objectives, centering adjustable nosepiece, anti-fungal optics.

Focus System
Coaxial coarse and fine focus mechanism, rack and pinion movement.

Spare Parts
Spare halogen lamp, fuse, dust cover, immersion oil included.

Theory
Designed for polarizing observation and research of minerals, materials, and geological specimens.

Drawtube
Trinocular (photographic) drawtube for simultaneous viewing and imaging.

Sensor
Not included (camera optional).

Resolution
Depends on eyepiece and objective; optical resolution up to 1000x.

Interface
Camera port via trinocular head, USB interface available if camera is installed.

Frame Rate
Up to 30 fps (with compatible digital camera attachment).

Focal Distance
Tube length 160mm; working distance dependent on selected objective.

Magnification
Standard 40x, 100x, 400x (with supplied objectives and eyepieces); extendable up to 1000x.

Dimensions
Approx. 465 mm (H) x 235 mm (L) x 180 mm (W).

Focus Range
Coarse range 25mm; fine adjustment 0.002mm minimum increment.

Eyepieces
Wide Field 10x/18mm Pair with cross hair & pointer (high eye-point); optional 16x available.

Eyepiece Tube
Inclined at 30, 360 rotatable trinocular head.

Illumination
Transmitted Kohler illumination, halogen lamp 6V/20W (replaceable) with adjustable intensity.

Coarse Adjustment Range
25 mm travel.

Fine Adjustment Range
Minimum reading 0.002 mm.

Working Stage
Rotating round stage, 160 mm diameter, with 360 graduated scale and vernier reading 0.1.

Still Image Capture Resolution
Up to 5MP (with optional camera, not included).

Video Capture Resolution
Up to 1920x1080p (with optional digital camera, not included).

Image Format
Adaptable to JPG, BMP, PNG (via optional digital camera attachment).

Interpupillary Distance
53-75 mm adjustable.

Objective Achromatic
4x, 10x, 40x (S), 100x (oil, spring); Polarizing achromatic objectives.

Condenser
Abbe condenser NA 1.25 with iris diaphragm, swing-out polarizer, and centering mechanism.

Light Source
Halogen lamp 6V/20W; external power supply required.

Polarizer/Analyzer
Rotatable polarizer (below condenser), analyzer (in optical path, removable)

Power Supply
AC 220V / 110V selectable

Nosepiece
Quadruple, centerable, ball-bearing mounted

Body Material
Die-cast metal, powder-coated finish

Bertrand Lens
Swing-in/out type, centering adjustable for conoscopic and orthoscopic observation

Color Filter Slots
Provided for blue, green, neutral density (filters included)

Operating Ambient Temperature
0C to 40C

Mechanical Stage
Rotatable, locked at any position, smooth movement

Stage Scale Graduation
1 increments, vernier reading to 0.1

Base
Heavy, vibration-resistant, anti-slip feet

Lamp Socket
Removable lamp house for easy bulb replacement

ConXport Upright Polarizing Microscope PQR-500S Trade Information

FOB Port
Delhi

Payment Terms
Letter of Credit (L/C), Paypal, Telegraphic Transfer (T/T)

Supply Ability
15 Per Week

Delivery Time
6-7 Days

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia, Australia

Main Domestic Market
All India

Certifications
ISO,CE,FDA,WHO-GMP

About ConXport Upright Polarizing Microscope PQR-500S

Product Details

Eye-piece:	WF 10X-20mm, Reticule 10X-20mm (Crosshair Reticule 0.1mm)
Objectives:	Infinity plan objective 4X, 10X, 20X(s), and 40X(s)
Head:	Binocular/Trinocular 30, Rotatable 360, IPD: 50-75mm
Nosepiece:	Quadruple
Stage Revolving:	Rotatable 360, Centre Adjustable, Division 1, Venire division 6
Focus:	Coaxial Coarse and Fine Focus
Condenser:	Abbe N.A. 1.25 with iris diaphragm
Polarizing System:	Polarizing Analyzer, Bertrand Lens Slip-Red, 1/4 Slip, Quartz Wedge
Illumination:	LED 3.3W/3V, ISO-CE

Advanced Polarizing Functionality

Designed specifically for mineral and material research, the PQR-500S offers advanced polarizing capabilities with a swing-out Bertrand lens, adjustable polarizer and analyzer, and strain-free objectives, allowing precise conoscopic and orthoscopic observation. These features make it ideal for geology labs and research institutions requiring high precision.

High-Precision Mechanical Stage and Optics

The PQR-500S is equipped with a 360 graduated stage (vernier reading 0.1) and a ball-bearing mounted, centerable quadruple nosepiece. The wide field eyepieces, high eye-point, and coaxial coarse/fine focus provide clear, crisp images, while the durable, powder-coated die-cast metal body resists vibrations and maintains alignment.

Versatile Imaging and Illumination Options

The trinocular head supports direct viewing and simultaneous imaging via a USB-enabled camera (optional). The Kohler illumination, adjustable intensity, and supplied color filters (blue, green, neutral density) ensure optimal lighting for detailed specimen analysis. The removable lamp house and spare parts simplify maintenance and prolong instrument lifespan.

FAQs of ConXport Upright Polarizing Microscope PQR-500S:

Q: How do I utilize the polarizing features for mineral analysis with the PQR-500S microscope?

A: The microscope is designed for polarizing observation with a swing-in/out Bertrand lens, rotatable polarizer, and analyzer. To analyze minerals, position your sample on the rotating stage, adjust polarizer and analyzer angles for contrast, and use the Bertrand lens for conoscopic or orthoscopic methods, which highlight optical properties critical to mineral identification.

Q: What is the process for installing or replacing the illumination bulb?

A: The removable lamp house allows for quick and easy replacement. Simply switch off and unplug the microscope, slide out the lamp house from the base, replace the 6V/20W halogen bulb, and insert the lamp house back securely. Always handle bulbs with gloves to avoid fingerprints and extend lifespan.

Q: Where can I attach a camera to the microscope, and what are the benefits of this feature?

A: A camera can be attached via the trinocular drawtube. This enables real-time image capture and documentation, supporting up to 5MP resolution and video at 1920x1080p (with an optional camera). It is especially beneficial for sharing observations, archiving data, and educational demonstrations.

Q: When should I use the provided color filters during microscopic observation?

A: Color filters (blue, green, neutral density) should be used to enhance contrast and image clarity depending on the sample type and observation needs. For example, a blue filter improves color correction in transmitted halogen light, while neutral density filters reduce light intensity without altering color balance.

Q: How do I ensure consistent and precise sample positioning on the stage?

A: The mechanical stage is rotatable and can be locked at any position using its secure locking mechanism. Graduated scale and vernier reading let you fine-tune the angle (up to 0.1 precision) for accurate, repeatable positioningcritical for detailed analysis or multi-view documentation.

Q: What maintenance procedures should be followed to prolong the life of the microscope?

A: Keep optics dust-free using included dust cover when not in use, clean lenses gently with lens paper, replace halogen lamps promptly, and ensure anti-slip feet are clean and stable. Periodically check and lubricate mechanical components according to the manufacturers instructions for optimal performance.
