ConXport . HDMI Displayer for ULTRACAM Series Camera

Basic Performance

LCD Panel

Panasonic IPS LCD Screen(Super TFT)

Input Video Format

HDMI

Native Resolution

1920 x 1080

Display Type

16:9 Ratio 11.6 Inch Active Matrix Super TFT LCD

Typical Contrast Ratio

1000:1

Colors

16.7 Million

Viewing Angle(L/R/U/D)

IPS Full View

Active Display Area

258mm(W) x  145mm(H)

Pixel Pitch

0.134(W) X 0.134(H) mm

Brightness

350 cd/ sq.m ;400cd sq.m / Optional

Backlight

LED Backlight 5000 hours

Outline Parameter

Color

Black

Operating Environment

Operating Temperature

-15 Degree~55 Degree

Humidity Non Condensing

Operating:10%-90%, Storage: 5%-90%

Synchronization Range

30-80 KHz Horizontal, 55-75 Hz Vertical

Power Supply

AC110V-220V /DC12V(1A )

Power Consumption

Max 12W
