ConXport Fetal Monitor 7" Display

Get a Price/Quote

ConXport Fetal Monitor 7" Display Specification

Product Type
Fetal Monitor

Temperature Range
5C~40C

Use
Monitoring Fetal Heart Rate, Uterine Contractions

Color Code
White-Grey

Height
100 mm

Dimension (L*W*H)
305 x 270 x 100 mm

Storage Capacity
Up to 150 patient records

Shape
Rectangular

Material
ABS Plastic Housing

Suitable For
Pregnant Women, Hospitals, Clinics

Treatment Type
Non-Invasive Prenatal Monitoring

Weight
3.1 kg

Application
Obstetrics, Fetal Heart Rate Monitoring

Accuracy
1 bpm (Heart Rate), 10% (Contraction)

Power
50 VA (Max)

Function
Real-time Monitoring, Data Storage, Alarm

Frequency
50/60 Hz

Automation Grade
Automatic

Humidity Range
85% RH

Properties
Portable, Compact, Lightweight, High Sensitivity

Display Type
Digital, Color LCD

Phase
Single

Power Source
AC Mains / Built-in Battery

Display
7 inch TFT Color

Voltage
110V-240V AC

Alarm Type
Audio and Visual

Fetal Movement Indication
Manual Key

FHR Resolution
1 bpm

Interface
RS232, USB

Operation Mode
Manual / Auto

Accessories Included
FHR Probe, TOCO Probe, Thermal Paper, Power Cable

Paper Width
50/112 mm

TOCO Range
0-99 units

Transducer Type
Ultrasound for FHR, Pressure for TOCO

Battery Backup
Up to 4 hours continuous use

Safety Standard
IEC 60601-1

FHR Range
30-240 bpm

Operating Language
English

Built-in Printer
Yes (Thermal Printing)

Data Export
Yes (USB)

ConXport Fetal Monitor 7" Display Trade Information

FOB Port
Delhi

Payment Terms
Letter of Credit (L/C), Telegraphic Transfer (T/T), Paypal

Supply Ability
15 Per Week

Delivery Time
6-7 Days

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia

Main Domestic Market
All India

Certifications
ISO,CE,FDA

About ConXport Fetal Monitor 7" Display

Fetal Monitor Used ToContinuously Record The Heartbeat Of The Fetus And The Contractions Of TheWomans Uterus During Labor.

Fetal Monitor 7" Wide TFT ColorLCD Display

Up To 150 Patients Data Saving

Fetal Heart Sound Play And RecordIn PC

Rotation Screen

Water Proof Probe

GE / Philips Paper Compatible

Interpretation Function

Multiple Language Support

Built-In Quick Guide (LCD Type) WaterProof Probe

Twins Probe Available

Power Consumption : <20W

Dimension : 96 Mm (H) X 326 Mm (L)X 276 Mm (D)

Net Weight : 5.5 KG

Working Temperature :10-40 C, RelativeHumidity 10-80%

External Link : RS-232C

Trend : USB Data Saving

PC Interface (Central MonitoringSystem)

Optional : Rechargeable Battery

Advanced Real-Time Monitoring

The ConXport Fetal Monitor delivers real-time tracking of fetal heart rate and uterine contractions through its sensitive transducers. Its digital 7-inch color LCD ensures clear visualization of vital parameters, helping clinicians make timely decisions. This device supports both manual and automatic modes, adapting seamlessly to different monitoring protocols and clinical workflows.

Reliable Data Storage and Export Features

With storage capacity for up to 150 patient records, the monitor ensures comprehensive data management. USB export capability and RS232 interface make transferring and archiving data effortless, supporting hospital record-keeping and analysis. The built-in thermal printer allows instant documentation of readings for further review and patient communication.

User-Friendly and Safe Design

Engineered with practicality in mind, the monitor features easy-to-use controls, a lightweight ABS plastic housing, and a compact form factor. Built to IEC 60601-1 safety standards, it includes battery backup for up to four hours, ensuring uninterrupted operation. Accessories like FHR and TOCO probes, thermal paper, and power cable are included for immediate deployment.

FAQs of ConXport Fetal Monitor 7" Display:

Q: How does the ConXport Fetal Monitor measure fetal heart rate and contractions?

A: The monitor uses an ultrasound transducer to detect fetal heart rate (FHR) and a pressure transducer for uterine contraction (TOCO) measurements. These readings are displayed on a 7-inch digital color LCD in real time, ensuring accurate and immediate monitoring.

Q: What is the process for exporting patient data from the device?

A: Patient data can be conveniently exported via the devices USB port or RS232 interface. This allows clinicians to transfer records for digital archiving, further analysis, or sharing within healthcare information systems.

Q: When should the alarm function be used, and what types of alarms are available?

A: Alarms are automatically activated when readings fall outside preset safe ranges or require immediate attention. The monitor provides both audio and visual alarm notifications, alerting medical staff to take timely action.

Q: Where is the ConXport Fetal Monitor typically used?

A: The device is suitable for use in hospitals, maternity clinics, and womens healthcare centers. Its lightweight, portable design makes it ideal for regular check-ups, bedside monitoring, and emergency use during labor.

Q: What are the advantages of the built-in thermal printer?

A: The built-in thermal printer provides instant printouts of fetal monitoring data, enhancing documentation, facilitating quick reviews, and simplifying the sharing of information with patients or colleagues.

Q: How is the device powered and what is its battery backup duration?

A: The monitor operates on 110V-240V AC mains power, but it also includes a built-in battery offering up to four hours of continuous use. This ensures reliable operation during power interruptions or when mobility is required.
