Microscopes And Projector

• Coarse Adjustment Range
• Provided in vertical movement, up to 25 mm.

• Condenser
• Integrated condenser for uniform illumination.

• Dimensions
• Approx. 600 mm (H) x 350 mm (W) x 500 mm (D).

• Drawtube
• Other, Not applicable.

• Eyepiece Tube
• Not applicable.

• Eyepieces
• Not applicable (projection system, not viewing head).

• Features
• Fast sample placement, screen protractor, overlay chart, contour comparison, sturdy bench top design.

• Fine Adjustment Range
• Precision movement, 0.002 mm increments.

• Focal Distance
• Standard configuration ~50-100 mm adjustable.

• Focus Range
• Manual adjustment with coarse and fine focus.

• Focus System
• Coarse & fine manual focus knobs.

• Frame Rate
• Not applicable (static projection system).

• Illumination
• High-Intensity LED or Halogen Illumination System.

• Image Format
• Projected analog profile image on viewing screen.

• Interface
• Manual mechanical interface.

• Interpupillary Distance
• Not applicable.

• Light Source
• Halogen lamp (12V/100W) or LED module.

• Magnification
• 10x, 20x (standard), optional up to 50x.

• Objective Achromatic
• Achromatic projection lenses included.

• Resolution
• 0.01 mm.

• Sensor
• High-precision optical lens system.

• Spare Parts
• Replacement bulbs, projection lenses, glass screen.

• Still Image Capture Resolution
• Depends on overlay grid, up to 0.01 mm accuracy.

• Theory
• Other, Optical measurement using projection for precise profile analysis.

• Video Capture Resolution
• Not applicable.

• View Head
• Horizontal screen, circular viewing area approx. 300 mm diameter.

• Working Stage
• Glass stage, 200 mm x 150 mm with X-Y travel.

• Coarse Adjustment Range
• Depends on host microscope configuration.

• Condenser
• Not included; reliant on microscope.

• Dimensions
• Approx. 72 x 72 x 35 mm (varies by model)

• Drawtube
• Other, C-mount adaptable to various trinocular microscopes.

• Eyepiece Tube
• Not applicable; C-mount interface.

• Eyepieces
• Not included (direct camera-microscope connection via C-mount).

• Features
• Plug & play via USB 2.0, compatible with Windows OS, real-time imaging, image/video capture, user-friendly imaging software

• Fine Adjustment Range
• Dependent on host microscope

• Focal Distance
• Adjustable as per microscope and adapter specifications.

• Focus Range
• Controlled via connected microscopes focusing mechanism.

• Focus System
• Manual, through microscopes focus

• Frame Rate
• 15-25 frames per second (fps) at max resolution

• Illumination
• Utilizes microscopes existing illumination system.

• Image Format
• BMP, JPEG, TIFF, PNG; video - AVI

• Interface
• USB 2.0

• Interpupillary Distance
• Not applicable (camera module).

• Light Source
• Relies on microscope light source.

• Magnification
• Depends on associated microscope optics; standard for C-mount cameras.

• Objective Achromatic
• Not included; utilizes microscope objective.

• Resolution
• Available in multiple sensor resolutions such as 2.0 MP/5.0 MP/8.0 MP/10.0 MP, depending on the model.

• Sensor
• High-quality CMOS sensor

• Spare Parts
• USB cable, documentation, imaging software CD/USB

• Still Image Capture Resolution
• Up to native sensor MP (2/5/8/10MP options)

• Theory
• Other, Digital USB 2.0 CMOS camera designed for microscopy imaging applications.

• Video Capture Resolution
• 1280 x 1024, 1920 x 1080, model-dependent

• View Head
• Digital camera head

• Working Stage
• Determined by microscope model; not included.

• Coarse Adjustment Range
• Throughout the working range.

• Condenser
• Abbe condenser NA 1.25 with iris diaphragm.

• Dimensions
• Approx. 30 cm (H) x 20 cm (W) x 15 cm (D).

• Drawtube
• Other, Monocular Drawtube.

• Eyepiece Tube
• Straight tube for comfortable viewing.

• Eyepieces
• Standard WF10x eyepiece.

• Features
• Portable, lightweight design, digital output, easy to operate, suitable for field and lab use.

• Fine Adjustment Range
• Micro-level fine focusing adjustment.

• Focal Distance
• Adjustable focal distance depending on magnification.

• Focus Range
• Coarse and fine focusing available.

• Focus System
• Coarse and fine focus knob system.

• Frame Rate
• Up to 30 fps digital streaming.

• Illumination
• LED illumination with intensity adjustment.

• Image Format
• JPG, BMP, PNG supported by bundled software.

• Interface
• USB connectivity for PC/Laptop interface.

• Interpupillary Distance
• Fixed for monocular tube.

• Light Source
• LED lamp, rechargeable battery included.

• Magnification
• 100x, 400x, 1000x (with provided objective lenses).

• Objective Achromatic
• Achromatic objectives 10x, 40x, 100x.

• Resolution
• High-resolution digital output, up to 640 x 480 pixels.

• Sensor
• CMOS Digital Imaging Sensor.

• Spare Parts
• Eyepiece, objective lens, power cable, USB cable.

• Still Image Capture Resolution
• 640 x 480 pixels.

• Theory
• Other, Portable semen analysis using advanced digital imaging for microscopic study.

• Video Capture Resolution
• 640 x 480 pixels at 30 fps.

• View Head
• Monocular, rotatable.

• Working Stage
• Mechanical stage with slide holder and knobs for X-Y movement.

• Coarse Adjustment Range
• 30 mm / revolution

• Condenser
• NA 1.25 Abbe condenser, with iris diaphragm

• Dimensions
• Approx. 380 mm x 270 mm x 140 mm

• Drawtube
• Other, Monocular, Trinocular attachment available

• Eyepiece Tube
• Inclined at 45 for comfortable viewing

• Eyepieces
• WF10x/18mm or WF16x optional

• Features
• Live image preview, measurement software, image processing, plug & play, snapshot and video recording

• Fine Adjustment Range
• 0.002 mm / division

• Focal Distance
• 10mm 20mm (adjustable)

• Focus Range
• 0 30 mm mechanical movement

• Focus System
• Coaxial coarse and fine focusing

• Frame Rate
• Up to 30 fps

• Illumination
• Built-in LED with adjustable brightness

• Image Format
• JPEG, BMP, PNG

• Interface
• USB 2.0 / 3.0

• Interpupillary Distance
• 55 75 mm

• Light Source
• LED illumination with intensity control

• Magnification
• 40x 1000x (digital + optical)

• Objective Achromatic
• 4x, 10x, 40x(S), 100x(S, Oil)

• Resolution
• Up to 1920 x 1080 pixels

• Sensor
• High resolution digital CMOS sensor

• Spare Parts
• Dust cover, power adapter, spare bulb, immersion oil

• Still Image Capture Resolution
• 2MP, 5MP, 8MP (sensor dependent)

• Theory
• Other, Digital integration with traditional optical microscopy for enhanced imaging and analysis.

• Video Capture Resolution
• 1080P/720P/640 x 480 depending on sensor

• View Head
• Monocular standard, Trinocular option available

• Working Stage
• Mechanical stage 125mm x 115mm with X-Y movement

• Coarse Adjustment Range
• Up to 15mm travel.

• Condenser
• Built-in, NA 0.25 or higher, with iris diaphragm.

• Dimensions
• Approx. 350mm x 240mm x 520mm (L x W x H).

• Drawtube
• Other, Trinocular head, inclined at 45 for comfortable observation.

• Eyepiece Tube
• Trinocular, supports observation and camera connection simultaneously.

• Eyepieces
• Widefield 10x (pair), optional 15x.

• Features
• Ergonomic design, anti-fungal optical coatings, long working distance objectives, suitable for metallurgical sample inspection.

• Fine Adjustment Range
• 0.002mm precision fine focus.

• Focal Distance
• Dependent on objective lenses, typically 50mm to 200mm.

• Focus Range
• Coarse and fine focusing, total travel typically ~15mm.

• Focus System
• Coaxial coarse and fine focusing mechanism.

• Frame Rate
• Depends on digital camera used (not included); up to 30 fps possible.

• Illumination
• Built-in halogen lamp, 6V/20W, adjustable intensity.

• Image Format
• If camera is attached: JPEG/BMP with digital adapter (optional).

• Interface
• Mechanical slide holder, trinocular port for camera attachment (optional).

• Interpupillary Distance
• Adjustable 55-75mm.

• Light Source
• Internal halogen lamp, 6V/20W, intensity variable.

• Magnification
• 40x, 100x, 400x, and 1000x (with supplied objectives and eyepieces).

• Objective Achromatic
• Plan achromatic objectives: 4x, 10x, 40x, 100x (oil immersion).

• Resolution
• Depends on selected eyepiece and objective, generally up to 1000x magnification optical resolution.

• Sensor
• Not Applicable (optical microscope, no built-in digital sensor).

• Spare Parts
• Eyepiece, objective, lamp, fuse, dust cover.

• Still Image Capture Resolution
• Dependent on camera attachment (not native to microscope).

• Theory
• Other, Inverted Metallurgical Microscope for the analysis of metallurgical specimens.

• Video Capture Resolution
• Dependent on camera attachment (not native to microscope).

• View Head
• Trinocular, 45 inclined, rotatable 360.

• Working Stage
• Mechanical stage with X-Y movement, size 230mm x 140mm.

• Coarse Adjustment Range
• Up to 15 mm (approx)

• Condenser
• Abbe condenser, N.A. 1.25 with iris diaphragm

• Dimensions
• Approx. 270 (L) x 200 (W) x 370 (H) mm

• Drawtube
• Other, Monocular/Trinocular digital head (depending on model)

• Eyepiece Tube
• Inclined at 45 for easy viewing

• Eyepieces
• WF10x (Wide Field Eyepiece)

• Features
• Direct digital output, screen observation, easy USB connectivity, suitable for education, clinical, and research applications

• Fine Adjustment Range
• Up to 0.002 mm (approx)

• Focal Distance
• 10 mm - 50 mm (adjustable)

• Focus Range
• Fine and coarse adjustment available

• Focus System
• Coarse & fine focusing mechanism

• Frame Rate
• Up to 30 fps (Frames per Second)

• Illumination
• Incident and transmitted LED illumination with adjustable brightness

• Image Format
• JPEG, BMP, PNG or AVI for video

• Interface
• USB 2.0 / USB 3.0 compatible

• Interpupillary Distance
• 55 mm to 75 mm (on models with binocular/trinocular head)

• Light Source
• High power white LED, adjustable

• Magnification
• 40x to 1000x (optical and digital combined)

• Objective Achromatic
• 4x, 10x, 40x, 100x oil (standard set)

• Resolution
• Up to 5.0 MP (may vary by model)

• Sensor
• High-sensitivity CMOS Sensor

• Spare Parts
• Supplied with power adapter, dust cover, and basic software CD/USB

• Still Image Capture Resolution
• Up to 2592 x 1944 pixels

• Theory
• Other, Digital imaging and display for microscopy applications, allowing direct observation on screen.

• Video Capture Resolution
• Up to 1920 x 1080 pixels

• View Head
• 360 rotatable head (for ergonomic viewing)

• Working Stage
• Mechanical stage with scale, 110 x 125 mm

• Coarse Adjustment Range
• 30mm

• Condenser
• Not applicable (stereo microscopy)

• Dimensions
• Approx. 340mm x 270mm x 340mm

• Drawtube
• Other, Binocular, 45 inclined

• Eyepiece Tube
• Binocular, rotatable 360

• Eyepieces
• WF10x / 20mm

• Features
• Zoom magnification, digital imaging, ergonomic design, anti-fungus optics, wide viewing field

• Fine Adjustment Range
• 5mm

• Focal Distance
• 100mm to 140mm (adjustable)

• Focus Range
• 50mm to 80mm (coarse and fine adjustment)

• Focus System
• Coarse and fine focus knobs

• Frame Rate
• 30fps at full resolution

• Illumination
• LED ring light (incident) and transmitted base illumination

• Image Format
• JPEG, BMP for still image; AVI, MJPEG for video

• Interface
• USB 2.0 / AV

• Interpupillary Distance
• 55mm to 75mm

• Light Source
• LED (adjustable brightness)

• Magnification
• 7x to 45x (zoom)

• Objective Achromatic
• Zoom objective 0.7x 4.5x, achromatic

• Resolution
• 1920 x 1080 pixels

• Sensor
• High Definition CMOS digital sensor

• Spare Parts
• Spare eyepiece, fuse, dust cover, cleaning cloth

• Still Image Capture Resolution
• 1920 x 1080 pixels

• Theory
• Other, Provides clear, high-contrast 3D observation with advanced digital imaging capability, suitable for inspection and assembly tasks.

• Video Capture Resolution
• 1920 x 1080 pixels

• View Head
• Binocular, 360 rotatable, inclined at 45

• Working Stage
• Rectangular, with frosted glass and black/white plate

• Coarse Adjustment Range
• 50 mm

• Condenser
• Not applicable (not required in stereo microscopes)

• Dimensions
• Approx. 330 mm (H) x 290 mm (L) x 260 mm (W)

• Drawtube
• Other, Binocular/Trinocular

• Eyepiece Tube
• Inclined 45, rotatable 360

• Eyepieces
• Wide Field 10x/20mm (pair)

• Features
• Digital imaging, sharp stereo vision, compact design, easy USB/HDMI connectivity, adjustable illumination

• Fine Adjustment Range
• Not applicable (generally coarse focus only for stereo microscopes)

• Focal Distance
• 100 mm (with standard objective)

• Focus Range
• 50 mm (vertical) manual focus

• Focus System
• Manual, rack and pinion mechanism

• Frame Rate
• 30 fps (camera dependent)

• Illumination
• Top and bottom LED illumination, intensity adjustable

• Image Format
• JPG, BMP, PNG (camera dependent)

• Interface
• USB 2.0, HDMI (model dependent)

• Interpupillary Distance
• 55 mm 75 mm adjustable

• Light Source
• LED, white light, long life, intensity adjustable

• Magnification
• 7x to 45x (standard), extendable with auxiliary objectives/eyepieces

• Objective Achromatic
• 0.7x 4.5x zoom objective (Achromatic)

• Resolution
• Up to 5 megapixels (camera dependent)

• Sensor
• High-sensitivity digital CMOS sensor

• Spare Parts
• Dust cover, spare LED bulb, rubber eyecups

• Still Image Capture Resolution
• Up to 2592 x 1944 pixels (camera dependent)

• Theory
• Other, ConXport Digital Stereo Zoom Microscope offers simultaneous observation of images with a digital imaging system and wide field eyepieces, suitable for high-resolution stereoscopic analysis.

• Video Capture Resolution
• Up to 1080p Full HD (camera dependent)

• View Head
• Trinocular/ Binocular, rotatable

• Working Stage
• Black & white reversible plate with stage clips

• Coarse Adjustment Range
• 30 mm coarse adjustment.

• Condenser
• Swing-out type, NA 0.9 with iris diaphragm.

• Dimensions
• Approx. 380 mm x 260 mm x 400 mm.

• Drawtube
• Other, Trinocular head, allowing attachment of camera for photomicrography.

• Eyepiece Tube
• Inclined 45, rotatable 360, comfortable for extended use.

• Eyepieces
• Wide field 10X/18 mm and 15X (optional).

• Features
• Sturdy construction, anti-fungus coated optics, suitable for educational and industrial labs.

• Fine Adjustment Range
• 0.002 mm fine adjustment.

• Focal Distance
• Objective focal length 30180 mm depending on selected objective lens.

• Focus Range
• Coaxial coarse and fine focusing system; coarse adjustment range: 30 mm, fine adjustment range: 0.002 mm.

• Focus System
• Coarse and fine coaxial focus system.

• Frame Rate
• Up to 30 fps (with digital camera attachment).

• Illumination
• Koehler illumination with built-in halogen lamp (6V/20W), adjustable intensity.

• Image Format
• Supports JPG, BMP formats (with optional camera).

• Interface
• Standard coaxial pin for camera attachment, USB output with digital camera.

• Interpupillary Distance
• Adjustable from 5575 mm.

• Light Source
• Halogen lamp 6V/20W; LED optional.

• Magnification
• Total magnification range from 100X to 1000X (objectives 10X, 40X, 100X; eyepieces 10X, 15X).

• Objective Achromatic
• Achromatic objectives 10X, 40X (spring), 100X (oil immersion).

• Resolution
• Up to 0.002 mm optical resolution.

• Sensor
• Compatible with 1/3 CMOS/CCD camera adapter (camera optional).

• Spare Parts
• Replacement bulbs, eyepieces, and immersion oil included.

• Still Image Capture Resolution
• Up to 1920 x 1080 pixels (with camera).

• Theory
• Other, Metallurgical microscope designed for observation of the microstructure of metals and alloys.

• Video Capture Resolution
• Full HD 1080p (with optional camera).

• View Head
• Trinocular head inclined at 45, 360 rotatable.

• Working Stage
• Rectangular double-layer mechanical stage 135 x 140 mm, movement range 75 x 50 mm.

• Coarse Adjustment Range
• Up to 50mm with rapid vertical movement control.

• Condenser
• Built-in condenser with adjustable aperture control for illumination uniformity.

• Dimensions
• Approx. 750mm x 400mm x 900mm.

• Drawtube
• Other, Standard, durable mechanical drawtube for optical alignment.

• Eyepiece Tube
• Binocular tube, inclined for comfortable viewing.

• Eyepieces
• Wide field eyepiece, 10x (Optional: 15x and 20x available).

• Features
• Highly precise profile measurement, long-lasting construction, micro-focus capability, variable illumination, easy calibration, compatible with digital display systems.

• Fine Adjustment Range
• Fine adjustment knob allowing 0.001mm increments.

• Focal Distance
• Variable focal distance adjustable according to the objective lens used.

• Focus Range
• Manual and fine focus adjustment, range up to 50mm for precise focusing.

• Focus System
• Mechanical focusing system with fine and coarse adjustment.

• Frame Rate
• Real-time image visualization up to 30fps (when optional camera system is installed).

• Illumination
• Halogen light source, with adjustable intensity for sharp profile projection.

• Image Format
• Analog and digital image support, compatible with JPEG, BMP formats.

• Interface
• Multi-functional interface supporting micrometer, digital readout, and compatible with measurement software.

• Interpupillary Distance
• Adjustable from 55mm to 75mm for customized operator comfort.

• Light Source
• High-powered halogen lamp 12V/100W for clear and bright profile images.

• Magnification
• Standard screen magnification available in 10x, 20x, 50x, 100x (Optional: higher magnifications available).

• Objective Achromatic
• High-precision achromatic objectives, standard 5x, 10x, 20x, 50x.

• Resolution
• Screen resolution up to 0.001mm for fine measurement accuracy.

• Sensor
• High-precision optical sensor system for accurate image capture.

• Spare Parts
• Available: replacement bulbs, glass stage inserts, eyepieces, objective lenses.

• Still Image Capture Resolution
• Optional digital system capable of up to 5MP still image capture.

• Theory
• Other, Horizontal Profile Projectors are used for precise measurement and inspection of profiles, contours, and surface features in metallurgical, engineering, and industrial applications.

• Video Capture Resolution
• Supports up to 1080p HD video capture with integrated camera (optional).

• View Head
• Horizontal, fixed head for easy profile observation.

• Working Stage
• Horizontal precision stage with glass insert, rotary and linear movements, measuring area typically 300mm x 100mm.

• Coarse Adjustment Range
• Available, vertical movement of approx. 15-20 mm.

• Condenser
• Fixed condenser lens, with disc diaphragm.

• Dimensions
• Approx. 33 x 16 x 12 cm (HxDxW).

• Drawtube
• Other, Monocular, 360 rotatable for convenient viewing.

• Eyepiece Tube
• Monocular tube inclined at 45 for comfortable viewing.

• Eyepieces
• Wide field 10x (WF10x).

• Features
• Robust metallic body, anti-fungal optical coating, lightweight and portable.

• Fine Adjustment Range
• Available, fine focus up to 2 mm or better.

• Focal Distance
• Variable, adjusted via coarse and fine focusing mechanisms.

• Focus Range
• Coarse and fine focusing range for precise adjustment.

• Focus System
• Coarse and fine focus adjustment knobs.

• Frame Rate
• Not applicable (non-digital).

• Illumination
• Plano-concave mirror for natural light; LED/halogen lamp available in some models.

• Image Format
• Not applicable (visual observation only).

• Interface
• No digital interface; manual operation.

• Interpupillary Distance
• Not adjustable (monocular).

• Light Source
• Reflecting mirror standard; LED optional in select models.

• Magnification
• Typically 40x, 100x, and 400x (using standard 10x eyepiece and 4x, 10x, 40x objectives).

• Objective Achromatic
• 3 achromatic objectives (4x, 10x, 40x).

• Resolution
• Optical resolution depends on objective used; typically up to 1000x total magnification.

• Sensor
• Not applicable (optical system, not digital).

• Spare Parts
• Eyepiece, objectives, mirror, stage clips (available as spares).

• Still Image Capture Resolution
• Not applicable (non-digital).

• Theory
• Other, Designed for student educational use, ideal for school laboratories and basic biological studies.

• Video Capture Resolution
• Not applicable (non-digital).

• View Head
• Monocular, 360 rotatable.

• Working Stage
• Fixed square stage with two stage clips.

• Coarse Adjustment Range
• 30mm travel

• Condenser
• NA (not used in profile projectors)

• Dimensions
• 300mm x 200mm x 450mm (L x W x H)

• Drawtube
• Other, Vertical Camera based

• Eyepiece Tube
• Not Applicable (camera-based system)

• Eyepieces
• Digital imaging system (no traditional eyepieces)

• Features
• Real-time image and video display, digital measurement tools, high magnification, LED illumination, USB and HDMI connectivity, low power consumption

• Fine Adjustment Range
• 5mm precision adjustment

• Focal Distance
• Adjustable from 50mm to 250mm

• Focus Range
• Manual and digital focus; range up to 100mm

• Focus System
• Manual & digital focus controls

• Frame Rate
• 30 fps (Full HD video)

• Illumination
• LED transmitted and reflected illumination, intensity adjustable

• Image Format
• JPEG, BMP, PNG, TIFF

• Interface
• USB 2.0 / 3.0, HDMI output

• Interpupillary Distance
• Not Applicable (camera-based system)

• Light Source
• High-intensity LED, white light

• Magnification
• 5x, 10x, 20x objectives, digital zoom available

• Objective Achromatic
• Plan Achromatic Lenses (5x, 10x, 20x)

• Resolution
• 1920 x 1080 pixels (Full HD)

• Sensor
• High resolution CMOS digital image sensor

• Spare Parts
• LED illumination module, glass stage, power supply, USB cable

• Still Image Capture Resolution
• 1920 x 1080 pixels

• Theory
• Other, Profile Projector is used for precise measurement and inspection of various shapes and objects in the field of engineering and manufacturing.

• Video Capture Resolution
• 1920 x 1080 pixels

• View Head
• Vertical, camera based digital output

• Working Stage
• Glass stage with scale grid, 150mm x 150mm

• Coarse Adjustment Range
• 25 mm travel.

• Condenser
• Abbe condenser NA 1.25 with iris diaphragm, swing-out polarizer, and centering mechanism.

• Dimensions
• Approx. 465 mm (H) x 235 mm (L) x 180 mm (W).

• Drawtube
• Other, Trinocular (photographic) drawtube for simultaneous viewing and imaging.

• Eyepiece Tube
• Inclined at 30, 360 rotatable trinocular head.

• Eyepieces
• Wide Field 10x/18mm Pair with cross hair & pointer (high eye-point); optional 16x available.

• Features
• 360 rotating stage with vernier, analyzer and polarizer, Bertrand lens for conoscopic and orthoscopic observations, strain-free objectives, centering adjustable nosepiece, anti-fungal optics.

• Fine Adjustment Range
• Minimum reading 0.002 mm.

• Focal Distance
• Tube length 160mm; working distance dependent on selected objective.

• Focus Range
• Coarse range 25mm; fine adjustment 0.002mm minimum increment.

• Focus System
• Coaxial coarse and fine focus mechanism, rack and pinion movement.

• Frame Rate
• Up to 30 fps (with compatible digital camera attachment).

• Illumination
• Transmitted Kohler illumination, halogen lamp 6V/20W (replaceable) with adjustable intensity.

• Image Format
• Adaptable to JPG, BMP, PNG (via optional digital camera attachment).

• Interface
• Camera port via trinocular head, USB interface available if camera is installed.

• Interpupillary Distance
• 53-75 mm adjustable.

• Light Source
• Halogen lamp 6V/20W; external power supply required.

• Magnification
• Standard 40x, 100x, 400x (with supplied objectives and eyepieces); extendable up to 1000x.

• Objective Achromatic
• 4x, 10x, 40x (S), 100x (oil, spring); Polarizing achromatic objectives.

• Resolution
• Depends on eyepiece and objective; optical resolution up to 1000x.

• Sensor
• Not included (camera optional).

• Spare Parts
• Spare halogen lamp, fuse, dust cover, immersion oil included.

• Still Image Capture Resolution
• Up to 5MP (with optional camera, not included).

• Theory
• Other, Designed for polarizing observation and research of minerals, materials, and geological specimens.

• Video Capture Resolution
• Up to 1920x1080p (with optional digital camera, not included).

• View Head
• Trinocular, 360 rotatable, inclined at 30.

• Working Stage
• Rotating round stage, 160 mm diameter, with 360 graduated scale and vernier reading 0.1.

• Coarse Adjustment Range
• Up to 20 mm

• Condenser
• N.A. 1.25 Abbe condenser with iris diaphragm and filter holder

• Dimensions
• Approx. 455 mm x 285 mm x 395 mm (LxWxH)

• Drawtube
• Other, Trinocular; 45 inclined, 360 rotatable

• Eyepiece Tube
• Trinocular head with diopter adjustment on one side

• Eyepieces
• Wide field 10X/18mm, paired set

• Features
• Equipped with high-efficiency fluorescence attachment, mechanical stage, easy switching between brightfield and fluorescence, robust metal body, anti-fungal optics.

• Fine Adjustment Range
• 0.002 mm per division

• Focal Distance
• Adjustable, typically 5575 mm interpupillary distance

• Focus Range
• Coarse: 20 mm; Fine: 0.002 mm precision

• Focus System
• Coaxial coarse & fine focusing mechanism with adjustable tension

• Frame Rate
• Up to 30 fps (with compatible camera, not included)

• Illumination
• LED lamp for transmitted light, 100 W high-pressure mercury lamp for fluorescence

• Image Format
• JPG, BMP, PNG (with compatible camera/software)

• Interface
• USB 2.0 (for camera connectivity)

• Interpupillary Distance
• 5575 mm adjustable

• Light Source
• 100 W mercury lamp (fluorescence); LED transmitted light

• Magnification
• 40X 1000X (using 4X, 10X, 40X, 100X objectives and 10X eyepieces)

• Objective Achromatic
• DIN Achromatic 4X, 10X, 40X (spring), 100X (spring, oil)

• Resolution
• Up to 1920x1080 (with compatible camera, not included)

• Sensor
• High sensitivity CMOS/CCD camera compatible (camera not included)

• Spare Parts
• Supplied with spare halogen & mercury lamp, fuses, dust cover, immersion oil, and power cord

• Still Image Capture Resolution
• Up to 5MP (dependent on camera, not included)

• Theory
• Other, A fluorescent research microscope uses fluorescence and phosphorescence techniques for high sensitivity observation, especially useful in biomedical and life science applications.

• Video Capture Resolution
• Up to 1920x1080 (dependent on camera, not included)

• View Head
• Trinocular, 45 inclined and 360 rotatable, suitable for photomicrography

• Working Stage
• Double layer mechanical stage, 140 mm x 135 mm, with vernier scale and low-position coaxial controls; moving range 75 mm x 50 mm

• Coarse Adjustment Range
• 30 mm

• Condenser
• Abbe condenser NA 1.25 with iris diaphragm and filter holder.

• Dimensions
• Approx. 430 mm 300 mm 480 mm.

• Drawtube
• Other, Trinocular, 30 inclined, rotatable 360.

• Eyepiece Tube
• Trinocular tube for simultaneous eyepiece viewing and camera mounting.

• Eyepieces
• Wide field 10x/22mm paired eyepieces.

• Features
• Modular fluorescence attachment, ergonomic design, digital imaging capability, anti-fungal coated optics, smooth focusing mechanism.

• Fine Adjustment Range
• 0.002 mm

• Focal Distance
• 45 mm (standard parfocal distance).

• Focus Range
• Coarse: 30 mm, Fine: 0.002 mm precision.

• Focus System
• Coaxial coarse and fine focusing system with tension adjustment.

• Frame Rate
• 30 fps at full HD resolution (camera dependent).

• Illumination
• LED or Mercury vapor fluorescent light source with adjustable intensity.

• Image Format
• JPG, PNG, TIFF, BMP (for still images), AVI or MP4 (for video capture).

• Interface
• USB 2.0/3.0 digital camera port, HDMI compatibility.

• Interpupillary Distance
• 55 75 mm adjustable.

• Light Source
• High intensity LED or mercury vapor fluorescent illuminator, 5W to 100W depending on configuration.

• Magnification
• 40x 1000x (with standard objectives and eyepieces).

• Objective Achromatic
• Plan Achromatic 4x, 10x, 40x (S), 100x (S, Oil) objectives.

• Resolution
• 1920 x 1080 pixels (camera), optical resolving power up to 0.2 m.

• Sensor
• High sensitivity imaging sensor for fluorescence applications.

• Spare Parts
• Dust cover, immersion oil, fuse, spare bulb/LED module, eyecups.

• Still Image Capture Resolution
• 1920 x 1080 pixels (camera dependent).

• Theory
• Other, Used for advanced fluorescent research applications, allowing observation of specimens using various fluorescence modes.

• Video Capture Resolution
• Up to 1080p (1920 x 1080 pixels).

• View Head
• Trinocular, 30 inclined, rotatable 360.

• Working Stage
• Double layer mechanical stage, size approx. 140 x 140 mm, moveable range 75 x 55 mm.

• Coarse Adjustment Range
• 40 mm

• Condenser
• N.A. 0.9 Abbe condenser

• Dimensions
• 450 x 280 x 550 mm

• Drawtube
• Other, Standard drawtube for smooth operation.

• Eyepiece Tube
• Binocular with diopter adjustment

• Eyepieces
• WF10x/22 mm

• Features
• High contrast imaging, precise calibration, easy digital interface

• Fine Adjustment Range
• 2 microns

• Focal Distance
• 170 mm

• Focus Range
• 50 mm continuous

• Focus System
• Coarse and fine focus controls

• Frame Rate
• 60 fps

• Illumination
• LED 6V/30W built-in illumination system

• Image Format
• JPEG, BMP, PNG

• Interface
• USB, HDMI

• Interpupillary Distance
• 55-75 mm adjustable

• Light Source
• Adjustable LED illumination, 6V/30W

• Magnification
• 10x, 20x, 50x, 100x interchangeable objectives

• Objective Achromatic
• Plan Achromatic objectives

• Resolution
• 0.001 mm

• Sensor
• High-sensitivity photoelectric sensor integrated.

• Spare Parts
• Eyepieces, objectives, LED bulb, fuse, stage clips

• Still Image Capture Resolution
• 1920 x 1080 pixels

• Theory
• Other, Co-Axial Optical Projector for precise profile measurements.

• Video Capture Resolution
• Full HD 1080p

• View Head
• Trinocular and Binocular options

• Working Stage
• Rotatable stage 200 x 150 mm

• Coarse Adjustment Range
• 30 mm

• Condenser
• Abbe condenser N.A. 1.25, with iris diaphragm and filter mount

• Dimensions
• Approx. 450 mm x 300 mm x 300 mm (HxWxD)

• Drawtube
• Other, Trinocular (for camera attachment and eyepiece observation)

• Eyepiece Tube
• Trinocular, inclined at 30

• Eyepieces
• WF 10x/18 mm paired (with diopter adjustment on one eyepiece)

• Features
• Precise focus system, wide field eyepieces, modular filter system for fluorescence, mechanical stage with large travel, robust metal frame

• Fine Adjustment Range
• 0.002 mm per division

• Focal Distance
• 185 mm

• Focus Range
• 30 mm (complete coarse and fine focus movement)

• Focus System
• Coaxial coarse and fine focusing system

• Frame Rate
• Dependent on attached camera sensor (typically up to 30 fps with digital imaging)

• Illumination
• LED Fluorescent epi-illuminator (Mercury lamp optional/available), with transmitted LED illumination for bright field observation

• Image Format
• Supports digital image output when camera attached; compatible with JPG, TIFF, BMP depending on camera

• Interface
• Trinocular port for photomicrography or digital imaging system connection

• Interpupillary Distance
• 5075 mm (adjustable)

• Light Source
• High intensity LED (fluorescent blue and green excitation filters); mercury lamp optional

• Magnification
• 40x to 1600x (using supplied eyepieces and objectives)

• Objective Achromatic
• Plan Achromatic objectives; 4x, 10x, 40x (spring), 100x (spring, oil immersion)

• Resolution
• Dependent on attached camera; optical imaging up to approx. 2000x (with provided objectives and eyepieces)

• Sensor
• Compatible with digital camera sensors (CCD/CMOS, not included)

• Spare Parts
• Supplied with spare fuse, immersion oil, dust cover, and extra bulb

• Still Image Capture Resolution
• Dependent on camera (up to 20MP possible with compatible digital camera)

• Theory
• Other, Designed for fluorescent observation and research, suitable for advanced biological and medical applications.

• Video Capture Resolution
• Dependent on camera, typically up to Full HD or higher

• View Head
• Trinocular Siedentopf head, 360 rotatable, inclined at 30

• Working Stage
• Mechanical stage 140 x 145 mm; moving range 75 x 45 mm; coaxial control knobs

• Coarse Adjustment Range
• Provided via side knobs for stage elevation.

• Condenser
• Abbe condenser, NA 1.25 with iris diaphragm.

• Dimensions
• Compact, bench-top design (typically approx. 35cm x 18cm x 12cm).

• Drawtube
• Other, Monocular, straight tube.

• Eyepiece Tube
• Single monocular tube.

• Eyepieces
• WF 10x (Wide Field).

• Features
• Robust metal construction, suitable for student and classroom use.

• Fine Adjustment Range
• Built-in for precise focusing.

• Focal Distance
• Standard focal distance based on objective used (typically 160mm for biological microscopes).

• Focus Range
• Both coarse and fine adjustment options included.

• Focus System
• Coarse and fine focusing mechanism.

• Frame Rate
• Not Applicable (no digital components).

• Illumination
• Plano concave mirror; provision for sub-stage lamp (lamp not included).

• Image Format
• Direct visual observation (no digital output).

• Interface
• Manual operation; no digital connectivity.

• Interpupillary Distance
• Fixed, compatible with monocular viewing.

• Light Source
• Mirror (Plano concave); lamp provision only.

• Magnification
• Achromatic objectives 10x, 45x, 100x; Eyepiece 10x; Total magnification up to 1000x.

• Objective Achromatic
• Three objectives (10x, 45x, 100x oil immersion), achromatic corrected.

• Resolution
• Dependent on objective and eyepiece combination, typically up to 1000x optical resolution.

• Sensor
• Not Applicable (Optical Viewing).

• Spare Parts
• Eyepiece, objectives, mirror, condenser available.

• Still Image Capture Resolution
• Not Applicable (visual only).

• Theory
• Other, Optical microscopy using transmitted light for specimen observation.

• Video Capture Resolution
• Not Applicable (visual only).

• View Head
• Monocular vertical viewing.

• Working Stage
• Square mechanical stage with slide clips.

• Coarse Adjustment Range
• Up to 15mm.

• Condenser
• NA 1.25 Abbe condenser with iris diaphragm and filter holder.

• Dimensions
• Approx. 340 x 200 x 130 mm.

• Drawtube
• Other, Monocular, 360 rotatable.

• Eyepiece Tube
• Straight monocular tube, inclined at 45 for viewing comfort.

• Eyepieces
• Pair of WF10X and WF15X included.

• Features
• Robust metal construction, anti-fungal optics, portable handle, vibration-free base.

• Fine Adjustment Range
• Up to 0.002mm per division.

• Focal Distance
• Approx. 5-45 mm (depending on objective lens used).

• Focus Range
• Coarse: 15mm; Fine: 0.002mm precision.

• Focus System
• Coaxial coarse and fine focusing system with sturdy knobs.

• Frame Rate
• NA (No built-in camera in standard unit).

• Illumination
• Built-in LED illumination with adjustable intensity; mirror for natural light.

• Image Format
• NA (Standard Optical Model); optional camera offers JPEG format stills.

• Interface
• Direct visual (no digital output); optional camera port for digital models.

• Interpupillary Distance
• NA (Single eyepiece model).

• Light Source
• LED light with variable intensity or plano-concave mirror.

• Magnification
• 40X to 1000X (with Achromatic objectives and 10X eyepiece).

• Objective Achromatic
• Achromatic objectives 4X, 10X, 40X(S), 100X(S, Oil).

• Resolution
• Optical, dependent on eyepiece and objective combination.

• Sensor
• NA (Optical Microscope, no digital sensor included by default).

• Spare Parts
• Supplied with spare bulb, fuse, and optional immersion oil bottle.

• Still Image Capture Resolution
• NA (Available with optional camera accessory).

• Theory
• Other, Used for rapid and accurate malaria parasite detection in blood smears through microscopy.

• Video Capture Resolution
• NA (Available with optional camera accessory).

• View Head
• Monocular, 360 rotatable, inclined for comfort.

• Working Stage
• Mechanical stage 125 x 115 mm with graduated scale and two slide clips.

• Coarse Adjustment Range
• 30 mm

• Condenser
• Abbe condenser with iris diaphragm and filter holder

• Dimensions
• Approx. 600 x 300 x 380 mm (L x W x H)

• Drawtube
• Other, Binocular with Interpupillary Adjustment

• Eyepiece Tube
• Binocular

• Eyepieces
• Wide Field 10x paired sets (2 sets supplied)

• Features
• Simultaneous observation of two samples, split or merged field view, dual independent focusing, camera attachment provision, rugged metallic body

• Fine Adjustment Range
• 2 mm

• Focal Distance
• Adjustable, as per objective specification

• Focus Range
• Adjustable via coarse and fine mechanism

• Focus System
• Coarse and fine focusing with coaxial controls on both sides

• Frame Rate
• Not Applicable (unless camera fitted)

• Illumination
• Incident (Top) and Transmitted (Bottom) Halogen/LED illumination with variable control

• Image Format
• Visual/Direct Eyepiece, Optional Digital Output

• Interface
• Manual/Optical, Optional Camera Attachment

• Interpupillary Distance
• 5575 mm adjustable

• Light Source
• Halogen lamp or LED, variable intensity control, 6V/20W or equivalent

• Magnification
• 10x to 100x (Achromatic Objectives 10x, 40x, 100x Oil)

• Objective Achromatic
• Paired sets of Achromatic Objectives (10x, 40x, 100x Oil)

• Resolution
• Optical, dependent on eyepiece and objective combination

• Sensor
• Not Applicable (Optical Viewing System)

• Spare Parts
• Supplied with extra halogen/LED bulb, fuses, and dust cover

• Still Image Capture Resolution
• Depends on optional digital camera (up to 5MP or higher with camera)

• Theory
• Other, A comparison microscope provides side-by-side viewing of two specimens for forensic, metallurgical, and biological analysis. It comprises two identical microscopes connected by an optical bridge, allowing images to be viewed simultaneously in a split-field.

• Video Capture Resolution
• Depends on optional digital camera (up to 1080p with camera)

• View Head
• Trinocular (Optional for Photomicrography)

• Working Stage
• Mechanical stages with coaxial drive, two separate stages for each specimen

• Coarse Adjustment Range
• Up to 30mm travel range

• Condenser
• Abbe condenser with iris diaphragm, NA 1.25

• Dimensions
• Approx. 480mm x 390mm x 230mm

• Drawtube
• Other, Binocular and Trinocular tubes available

• Eyepiece Tube
• Binocular and Trinocular options, 45 inclined, 360 rotatable

• Eyepieces
• WF10x paired (Interchangeable)

• Features
• Precision optical path, modular design for ease of sample comparison, robust metal frame, ergonomic operation for extended use

• Fine Adjustment Range
• 0.002mm precision movement

• Focal Distance
• 45mm (Standard Working Distance)

• Focus Range
• Coarse and Fine adjustment provided

• Focus System
• Coarse and fine coaxial focusing system

• Frame Rate
• Depends on attached camera (if digital option chosen)

• Illumination
• Koehler illumination with Halogen lamp or built-in LED; adjustable intensity

• Image Format
• Compatible with digital camera for JPEG/RAW output (if camera attached)

• Interface
• Eyepiece observation; Trinocular port for camera attachment

• Interpupillary Distance
• 55-75mm adjustable

• Light Source
• Halogen 6V/20W or LED, user selectable

• Magnification
• 40x to 400x (Standard); up to 1000x with optional accessories

• Objective Achromatic
• 4x, 10x, 40x, 100x

• Resolution
• Depends on eyepiece and objective configuration

• Sensor
• N/A (Eyepiece based visual observation)

• Spare Parts
• Spare lamps, eyepieces, objectives, stage clips and dust cover included

• Still Image Capture Resolution
• Up to 12MP (with suitable camera)

• Theory
• Other, A comparison microscope is used for side-by-side analysis of specimens, allowing two objects to be viewed simultaneously in a split-field visual format for forensic or analytical examination.

• Video Capture Resolution
• Full HD 1080p supported (with suitable camera)

• View Head
• Split-field dual viewing with synchronized movement

• Working Stage
• Mechanical stage, size approx. 140mm x 140mm, dual specimen holding clips

• Coarse Adjustment Range
• 20 mm

• Condenser
• Abbe condenser, N.A. 1.25 with iris diaphragm

• Dimensions
• 250 mm x 180 mm x 380 mm (approx.)

• Drawtube
• Other, Monocular inclined

• Eyepiece Tube
• Single tube, inclined at 45

• Eyepieces
• WF 10X paired with high eye point and wide field

• Features
• Real-time projection, easy digital capture, option to connect to TV/laptop, screen projection for classroom use.

• Fine Adjustment Range
• 2 mm

• Focal Distance
• 50 mm to infinity (adjustable)

• Focus Range
• 020 mm

• Focus System
• Coaxial coarse and fine focusing mechanism

• Frame Rate
• 30 frames per second (real-time visualization)

• Illumination
• Built-in LED illumination with adjustable brightness

• Image Format
• JPG, BMP for still images

• Interface
• USB 2.0 or HDMI output (model dependent)

• Interpupillary Distance
• 50-75 mm (fixed, for monocular only)

• Light Source
• High-intensity white LED

• Magnification
• 40x to 1600x (with changeable optical system)

• Objective Achromatic
• 4x, 10x, 40x (SL), 100x (SL) oil immersion

• Resolution
• 1920 1080 pixels

• Sensor
• High-definition digital CMOS sensor

• Spare Parts
• Eyepiece, objectives, fuse, dust cover

• Still Image Capture Resolution
• Up to 5 Megapixels (interpolated)

• Theory
• Other, Used for demonstration purposes and teaching; suitable for projecting slides and images onto a screen for a group.

• Video Capture Resolution
• Full HD 1080p

• View Head
• 360 rotatable monocular view head

• Working Stage
• Mechanical stage 120 x 120 mm with vernier scale

• Coarse Adjustment Range
• Dependent on microscope body

• Condenser
• Dependent on microscope (integrated with host)

• Dimensions
• Approx. 35 mm (diameter) x 65 mm (length)

• Drawtube
• Other, Fits standard 23.2mm microscope eyepiece tubes.

• Eyepiece Tube
• 23.2mm diameter

• Eyepieces
• Compatible with standard widefield eyepieces

• Features
• Plug-and-play, adjustable exposure, real-time viewing on PC, easy installation, works with multiple microscope models

• Fine Adjustment Range
• Dependent on microscope body

• Focal Distance
• Infinity-corrected optics supported

• Focus Range
• Manual focus through microscope mechanisms

• Focus System
• Manual through microscope

• Frame Rate
• Up to 30 fps at 640 x 480

• Illumination
• Via microscope light source

• Image Format
• JPEG, BMP, PNG supported

• Interface
• USB 2.0

• Interpupillary Distance
• N/A (single eyepiece use)

• Light Source
• Microscopes own illumination system

• Magnification
• 10x eyepiece equivalent

• Objective Achromatic
• Compatible with achromatic objective lenses

• Resolution
• 640 x 480 pixels

• Sensor
• CMOS sensor (color)

• Spare Parts
• USB cable, calibration software, user manual

• Still Image Capture Resolution
• 640 x 480 pixels

• Theory
• Other, Enables digital imaging and observation via microscope eyepiece.

• Video Capture Resolution
• 640 x 480 pixels

• View Head
• Adaptable to monocular, binocular, and trinocular heads

• Working Stage
• Standard microscope stage-compatible

• Coarse Adjustment Range
• Provided for large-scale sample focusing.

• Condenser
• Darkfield condenser with diffuser for gem analysis.

• Dimensions
• Approx. 370mm x 250mm x 380mm (L x W x H).

• Drawtube
• Other, Trinocular, inclined at 45 for comfortable viewing and camera attachment.

• Eyepiece Tube
• Inclined trinocular tube at 45, anti-fungal & anti-reflection coating.

• Eyepieces
• Wide field eyepieces, typically WF10X (supplied).

• Features
• Darkfield illumination, inclined trinocular head, rotatable stage, gem clamps, robust build for laboratory use.

• Fine Adjustment Range
• Precise control for high-resolution focusing.

• Focal Distance
• Adjustable via coarse and fine focusing knobs.

• Focus Range
• Coarse and fine adjustment provided for precision focusing.

• Focus System
• Coarse and fine coaxial knob adjustment.

• Frame Rate
• Based on external camera used (not inherent to microscope body).

• Illumination
• Reflected and transmitted halogen/LED light with adjustable intensity.

• Image Format
• Depends on attached camera (typically JPEG, BMP, etc.).

• Interface
• Trinocular port for imaging devices and cameras.

• Interpupillary Distance
• Adjustable from 55mm to 75mm.

• Light Source
• Fitted halogen/LED lamp (both transmitted and incident light).

• Magnification
• Zoom range 10X to 80X (using changeable objectives and eyepieces).

• Objective Achromatic
• Achromatic objectives for clear, color-corrected images.

• Resolution
• Optical resolution depends on objectives; up to 1000x total magnification clarity.

• Sensor
• Not specified (depends on camera used).

• Spare Parts
• Supplied with spare halogen/LED bulbs and fuse.

• Still Image Capture Resolution
• Depends on attached cameras specification.

• Theory
• Other, Highly precise optical system suitable for gemological research and analysis.

• Video Capture Resolution
• Depends on attached cameras specification.

• View Head
• Trinocular, inclined and rotatable.

• Working Stage
• Rotatable gemstone plate with gem clamps and dark field attachment.

• Coarse Adjustment Range
• 30 mm approx.

• Condenser
• Abbe condenser N.A. 1.25 with iris diaphragm and filter holder

• Dimensions
• Approx. 370x280x160 mm (HxDxW)

• Drawtube
• Other, Trinocular, inclined at 45 for comfortable viewing

• Eyepiece Tube
• Inclined at 45, rotatable 360

• Eyepieces
• WF10x (Wide Field, Pair, 18mm field number)

• Features
• Robust metal construction, ergonomic design, anti-fungal optics, suitable for prolonged use

• Fine Adjustment Range
• 0.002 mm per division

• Focal Distance
• Standard; precise focusing using coaxial coarse and fine controls

• Focus Range
• Coarse and fine focus adjustments provided

• Focus System
• Coaxial coarse and fine focus controls

• Frame Rate
• Depends on camera, typically up to 30 fps (when digital module attached)

• Illumination
• Built-in LED/halogen with adjustable intensity

• Image Format
• Depends on camera attached, typically JPEG, TIFF for digital modules

• Interface
• Trinocular port for camera attachment

• Interpupillary Distance
• Adjustable, 55-75 mm

• Light Source
• Built-in 6V/20W halogen or LED (varies by model)

• Magnification
• 40x-1000x (4x, 10x, 40x, 100x oil objectives with 10x eyepieces)

• Objective Achromatic
• Achromatic DIN 4x, 10x, 40x(S), 100x(S, Oil immersion)

• Resolution
• Optical, depends on combination of eyepiece and objective (up to 1000x with standard configuration)

• Sensor
• Not applicable (optical; digital camera attachable via trinocular port)

• Spare Parts
• Dust cover, fuse, immersion oil, spare bulb (if halogen) provided

• Still Image Capture Resolution
• Depends on camera module (not included as standard)

• Theory
• Other, Inclined Trinocular Microscope, suitable for routine laboratory work and research applications.

• Video Capture Resolution
• Depends on camera module (not included as standard)

• View Head
• Trinocular, inclined 45, rotatable 360

• Working Stage
• Mechanical stage, 125x115 mm with dual slide holder

• Coarse Adjustment Range
• Typically up to 20mm vertical travel.

• Condenser
• Not present (not required for this type of reflected light microscope).

• Dimensions
• Approx. 250mm x 180mm x 340mm (LxWxH).

• Drawtube
• Other, Binocular, inclined at 45 for comfortable viewing.

• Eyepiece Tube
• Inclined binocular head, rotatable 360.

• Eyepieces
• Wide Field 10X with optional 15X.

• Features
• Supplied with precision jewel tweezers; stable base; suitable for detailed visual inspection of gems and jewelry.

• Fine Adjustment Range
• Precise graduated mechanism for fine focusing.

• Focal Distance
• Working distance varies with magnification, typically between 60mm and 80mm.

• Focus Range
• Coarse and fine focusing, suitable for precise adjustments required in jewelry inspection.

• Focus System
• Coarse and fine adjustment via dual knob system.

• Frame Rate
• Not applicable (optical microscope).

• Illumination
• LED/halogen reflected light illumination, adjustable intensity.

• Image Format
• Not applicable (non-digital optical microscope).

• Interface
• Manual/Mechanical only, no electronic interface.

• Interpupillary Distance
• Adjustable, 55mm to 75mm.

• Light Source
• LED/halogen lamp, built-in and adjustable.

• Magnification
• Standard magnification ranges from 10X to 40X (using supplied objectives and eyepieces).

• Objective Achromatic
• 2X and 4X supplied; other options available.

• Resolution
• Dependent on eyepiece and objective combination (optical, not digital).

• Sensor
• Not applicable (optical microscope).

• Spare Parts
• Replacement jewel tweezers, bulbs, eyepieces, objectives.

• Still Image Capture Resolution
• Not applicable (no camera included).

• Theory
• Other, Inclined Binocular Microscope designed for detailed inspection and handling of jewelry and other small items.

• Video Capture Resolution
• Not applicable (no camera included).

• View Head
• Inclined binocular, 360 rotatable.

• Working Stage
• Adjustable stage with clamp to securely hold jewelry.

• Coarse Adjustment Range
• Up to 35 mm, using rack and pinion mechanism.

• Condenser
• Not present; transmitted light supplied via mirror/LED beneath stage.

• Dimensions
• Approx. 195 mm (W) x 255 mm (D) x 320 mm (H).

• Drawtube
• Other, Straight, vertical tube with interchangeable eyepiece capability.

• Eyepiece Tube
• Straight binocular tube.

• Eyepieces
• Wide field 10x and 20x, interchangeable.

• Features
• Wide field observation, stable base, rotatable head, dual illumination, easy focus operation.

• Fine Adjustment Range
• Not available; focus achieved by coarse adjustment only.

• Focal Distance
• 45 mm to 100 mm (varies according to model).

• Focus Range
• 35 mm vertical movement (approximate).

• Focus System
• Rack and pinion, coarse adjustment.

• Frame Rate
• Not applicable (no camera/digital function).

• Illumination
• Top (incident) and bottom (transmitted) LED or halogen illumination; selectable modes.

• Image Format
• Not applicable (no camera attachment in standard model).

• Interface
• No digital interface; direct manual control.

• Interpupillary Distance
• Adjustable, 55 mm to 75 mm.

• Light Source
• LED or optional halogen, dual illumination (top and bottom).

• Magnification
• 10x to 40x (standard with 10x & 20x eyepieces and 1x, 2x objectives).

• Objective Achromatic
• Achromatic objectives, typically 1x and 2x magnifications.

• Resolution
• Depends on eyepiece and objective combination; typically up to 100 lines/mm.

• Sensor
• Not applicable (manual optical viewing).

• Spare Parts
• Supplied: one pair extra eyepiece, replacement bulb, fuse.

• Still Image Capture Resolution
• Not applicable (no camera/digital function).

• Theory
• Other, Provides three-dimensional visualization for dissection and inspection work.

• Video Capture Resolution
• Not applicable (no camera/digital function).

• View Head
• Binocular, 360-degree rotatable head.

• Working Stage
• Round, frosted glass stage with black/white contrast plate; stage clips.

• Coarse Adjustment Range
• Standard microscope adjustment

• Condenser
• As per microscope

• Dimensions
• Approx. 60mm x 25mm

• Drawtube
• Other, Fits standard 23mm eyepiece tubes

• Eyepiece Tube
• 23mm diameter

• Eyepieces
• Replaces standard eyepiece

• Features
• Plug and play, compatible with most Windows systems, real-time image capture

• Fine Adjustment Range
• Standard microscope adjustment

• Focal Distance
• Adjustable as per microscope

• Focus Range
• Controlled by the microscope

• Focus System
• Microscope focus control

• Frame Rate
• 30 frames per second

• Illumination
• Depends on microscope

• Image Format
• JPEG, BMP, PNG, and more

• Interface
• USB 2.0 connection

• Interpupillary Distance
• Dependent on microscope

• Light Source
• Utilizes microscopes illumination

• Magnification
• Based on microscope objective, up to 1000x

• Objective Achromatic
• Subject to installed microscope objective

• Resolution
• 640 x 480 pixels

• Sensor
• High-quality CMOS sensor

• Spare Parts
• Adaptor rings (optional), USB cable

• Still Image Capture Resolution
• 640 x 480 pixels

• Theory
• Other, Digital imaging eyepiece for microscopes

• Video Capture Resolution
• 640 x 480 pixels

• View Head
• Compatible with monocular and binocular microscope heads

• Working Stage
• Dependent on base microscope

• Coarse Adjustment Range
• N/A (Handled by microscope)

• Condenser
• N/A (microscope dependent)

• Dimensions
• 30 mm (max cylinder diameter) x 90 mm (length), approx.

• Drawtube
• Other, 23.2 mm diameter, fits standard microscope eyepiece slot

• Eyepiece Tube
• Fits 23.2 mm tubes, adaptors for 30 mm and 30.5 mm available optionally

• Eyepieces
• Replacement for standard optical eyepiece

• Features
• Real-time preview, image/video capture, measurement software included, plug & play, cross-platform compatibility

• Fine Adjustment Range
• N/A (Handled by microscope)

• Focal Distance
• Adjustable, suitable for various microscopes

• Focus Range
• Manual focusing adjustment

• Focus System
• Manual focus, adjusted via microscope

• Frame Rate
• Up to 30 fps at lower resolutions, up to 10 fps at full resolution

• Illumination
• Depends on microscope illumination

• Image Format
• JPEG, BMP, TIFF, PNG (via software)

• Interface
• USB 2.0

• Interpupillary Distance
• N/A for single eyepiece camera

• Light Source
• Uses microscopes own light source

• Magnification
• Equivalent to 10x Eyepiece

• Objective Achromatic
• Depends on user-supplied microscope

• Resolution
• 5.0 Megapixels

• Sensor
• CMOS HD Sensor

• Spare Parts
• USB cable, software CD, calibration tools, adaptors

• Still Image Capture Resolution
• 5.0 MP (2592 x 1944 pixels)

• Theory
• Other, Digital Camera Eyepiece for Microscopes

• Video Capture Resolution
• Maximum 1280 x 1024 pixels

• View Head
• Direct digital image export to PC

• Working Stage
• N/A (Handled by microscope stage)

• Coarse Adjustment Range
• Microscope dependent

• Condenser
• Microscope dependent

• Dimensions
• approx. 55 mm x 80 mm x 40 mm

• Drawtube
• Other, C-mount compatible

• Eyepiece Tube
• C-mount adapter required

• Eyepieces
• Camera replaces eyepieces

• Features
• Plug-and-play via USB 2.0, compatible with Windows OS, real-time image display, easy integration with optical microscopes

• Fine Adjustment Range
• Microscope dependent

• Focal Distance
• Adjustable via microscope optics

• Focus Range
• Fine and coarse focusing via microscope

• Focus System
• Via connected microscope

• Frame Rate
• up to 30 fps at 640 x 480

• Illumination
• Microscope dependent (camera does not emit light)

• Image Format
• JPG, BMP, PNG

• Interface
• USB 2.0

• Interpupillary Distance
• Not applicable (monocular digital)

• Light Source
• Microscope dependent

• Magnification
• Depends on microscope objective used

• Objective Achromatic
• Microscope dependent

• Resolution
• 5.0 MP (2592 x 1944)

• Sensor
• High sensitivity CMOS sensor

• Spare Parts
• USB cable, software CD, C-mount adapter

• Still Image Capture Resolution
• 5.0 Megapixel

• Theory
• Other, CMOS digital imaging

• Video Capture Resolution
• up to 1080p

• View Head
• Digital image displayed on PC

• Working Stage
• Microscope stage

• Coarse Adjustment Range
• 30mm

• Condenser
• Epi-illuminator; NA not applicable

• Dimensions
• Approx. 420mm x 250mm x 460mm

• Drawtube
• Other, Trinocular, inclined at 45

• Eyepiece Tube
• 45 inclined, 360 rotatable

• Eyepieces
• WF10x (Wide Field) paired set

• Features
• Inverted design for observation of metallurgical specimens; sturdy construction; ergonomic viewing angle; high precision mechanics; smooth focusing; suitable for large samples; upgradable with digital imaging.

• Fine Adjustment Range
• 2m division per graduation

• Focal Distance
• 75mm (standard working distance depending on objective)

• Focus Range
• Coarse: 30mm; Fine: 2m precision

• Focus System
• Coaxial coarse & fine adjustment

• Frame Rate
• Dependent on optional camera (not included in standard package)

• Illumination
• 6V 20W Halogen Lamp, Variable intensity

• Image Format
• Dependent on camera attached (trinocular port), typically supports JPEG/PNG if camera used

• Interface
• Trinocular tube for camera attachment

• Interpupillary Distance
• 55mm 75mm adjustable

• Light Source
• 6V 20W Halogen lamp with adjustable brightness

• Magnification
• Standard 50X to 500X (expandable based on objective and eyepiece used)

• Objective Achromatic
• 4x, 10x, 40x (S) Metallurgical Achromatic objectives

• Resolution
• Optical resolution depends on objective and eyepiece combination

• Sensor
• Not applicable (optical microscope)

• Spare Parts
• Halogen lamp, fuse, dust cover, stage clips, eye guard, instruction manual

• Still Image Capture Resolution
• Based on attached camera specification

• Theory
• Other, Designed for metallurgical observation of opaque specimens and materials; suitable for industrial quality control, research, and analysis.

• Video Capture Resolution
• Based on attached camera specification

• View Head
• Inclined trinocular head, allows simultaneous viewing and imaging

• Working Stage
• Double-layer mechanical stage, size 180mm x 155mm, movement 75mm x 50mm
