ConXport Traction Unit Computerised with Bed

Get a Price/Quote

ConXport Traction Unit Computerised with Bed Specification

Temperature Range
10Â°C to 40Â°C

Color Code
White & Blue

Material
Mild Steel Frame with Padded Mattress

Application
Physiotherapy & Rehabilitation

Suitable For
Hospitals, Physiotherapy Clinics

Humidity Range
10% to 90% RH non-condensing

Height
Bed Height approx 90 cm

Treatment Type
Electro-mechanical Traction

Power
180 W

Accuracy
Traction Force: Â±5%

Function
Intermittent and Continuous Traction Modes

Storage Capacity
Up to 10 user programs

Weight
Approx. 85 kg

Dimension (L*W*H)
Approx. 206 x 72 x 90 cm

Shape
Rectangular with Traction Bed

Use
Lumbar and Cervical Traction Therapy

Properties
Microprocessor based controller for precise traction

Display Type
Alphanumeric LCD

Automation Grade
Automatic with Manual Override

Frequency
50/60 Hz

Product Type
Computerised Traction Unit with Bed

Phase
Single Phase

Voltage
220-240 V AC

Power Source
Electric

Display
Digital LCD Display

Mobility
Fitted with heavy-duty castor wheels with brakes

Remote Control
Hand-held patient remote included

Bed Type
Split, cushioned top, heavy-duty MS structure

Safety Features
Emergency stop switch and patient alarm

Accessories
Complete set with cervical, pelvic, thoracic belts, spreader bar

Programmable Memory
Stores customized user protocols

Traction Force Range
5 kg to 70 kg

Timer Setting
1–99 minutes digital timer

Control Modes
Static, intermittent, progressive, regressive

Noise Level
<55 dB during operation

ConXport Traction Unit Computerised with Bed Trade Information

FOB Port
Delhi

Payment Terms
Letter of Credit (L/C), Paypal, Telegraphic Transfer (T/T)

Supply Ability
12 Per Week

Delivery Time
7-8 Days

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia

Main Domestic Market
All India

Certifications
ISO, CE, FDA, WHO-GMP

About ConXport Traction Unit Computerised with Bed

Hi-Tractionmicro computer controlled unit for Intermittent / Constant, Lumbar - cum -Cervical Traction is based on solid- state circuitry.

Thethree section fixed height powder coated Bed with storage cabin underneath isan integral part of the time.

Technical:

TherapyModes :EIGHT Traction Modes for either Lumbar or Cervial Traction, in progressive,Regressive, Intermittent & Static Modes etc.

Memory/ Program :30 Treatment Patterns can be programmed & stored in non-volatile memory.(24 Programers are feeded and six programs are Free).

TractionForce :Adjustable from 05kg to 60kg.

BaseForce :Adjustable from 00kg to 54kg.

Auto-TensionAdjustment :The Set Traction force is automatically maintained throughout theoperations.

TractionHold Time : AjustableFrom 00 to 99 sec.

BaseTraction Hold Time : Adjustable From 00 to 99 sec.

TreatmentTime : Continuouslyadjustable from 00 to 99 minutes, with acoustic signal and automatic reductionof traction force.

Displays: DigitalDisplay of Traction Force, Base Force, TF Hold Time, BF Hold Time, TreatmentTime & Graphical Displays of Traction Mode.

Traction/ Patient Safety :

1.Automatic System Check in Software on Start of Traction.

2.High Force Signal is Activated if Traction Force is set above 18kg &Acceptance of High-Force is required before start of treatment.

3.Automatic Tension release when emergencies occur. Patient can stop with handheld switch.

4.Display of Error Contents.

5.Power Supply : 220-240V AC. (use Stabilizer)

TractionTable :

1.The Fixed Height Upholstered traction table is ideal for Horizontal Cervicaland Pelvic / Lumbar Traction.

2.The Lumbar Section Rolls freely on nylon rollers for friction free lumbar pull.This section can also be locked in any position if desired. Head section has anAdjustable incline.

3.Cervical Traction angle is controlled by adjustment of the angle adjustmentbracket.

4.Size : Table is 212cm X 68cm X 63cm high and comes complete with storage shelf.

Accessories:

AdjustableFlexion Stool,

HeadHalter,

Pelvic& Thoracic Belts.

Precise and Programmable Traction Therapy

This traction unit offers microprocessor-controlled delivery of forces ranging from 5 kg to 70 kg, ensuring consistent and precise treatment. The system is programmable with memory to store up to ten user-defined protocols, helping therapists tailor therapy for individual patient needs.

Comprehensive Safety and Comfort

The unit prioritizes patient safety thanks to an emergency stop switch and alarm, while its split cushioned top and mild steel frame provide maximum support. The included patient hand-held remote offers additional control, ensuring comfort throughout the treatment session.

Versatile Clinical Application

ConXports traction unit is suitable for both lumbar and cervical traction therapy, making it useful for a wide range of rehabilitation requirements in hospitals and physiotherapy clinics. The machine supports intermittent and continuous traction modes for varied physiotherapeutic treatments.

FAQs of ConXport Traction Unit Computerised with Bed:

Q: How does the ConXport Traction Unit Computerised ensure accurate traction force during therapy?

A: The unit utilizes a microprocessor-based controller to precisely regulate traction force from 5 kg to 70 kg, ensuring accuracy within 5%. This helps in delivering consistent and safe therapeutic procedures for each patient.

Q: What safety features are included in the traction unit for patient protection?

A: Safety features include an emergency stop switch and patient alarm. These allow for immediate intervention in case of discomfort or emergency, making the device reliable for clinical use.

Q: When should the traction unit be used during physiotherapy sessions?

A: The traction unit is suitable for prescribed lumbar or cervical traction therapy, typically during rehabilitation or pain management sessions as advised by a qualified physiotherapist in hospitals or clinics.

Q: Where is the ConXport Traction Unit best installed for optimal use?

A: This device is ideal for installation in hospital physiotherapy departments or rehabilitation clinics. Mobility is enhanced with heavy-duty castor wheels and brakes, allowing flexible placement and easy repositioning as needed.

Q: What is the process for setting up a therapy session with this traction unit?

A: Sessions are set up by selecting desired traction force, therapy mode (static, intermittent, progressive, regressive), and timer settings (from 199 minutes) via the digital LCD interface. Therapists may also use stored user programs for repeatable procedures.

Q: How does the bed design enhance patient comfort during traction therapy?

A: The split, cushioned top made of a durable mild steel frame and padded mattress provides ergonomic support, while included traction belts and bar ensure effective patient positioning and comfort throughout the session.

Q: What are the key benefits of using the ConXport Traction Unit for physiotherapy?

A: Benefits include precise traction control, customizable treatment protocols, comprehensive safety mechanisms, user-friendly remote operation, and suitability for both lumbar and cervical rehabilitation, contributing to effective pain relief and recovery.
