ConXport X-Ray Collimeter
ConXport X-Ray Collimeter
images Send Inquiry
Request To Call Back

ConXport X-Ray Collimeter

Get a Price/Quote

ConXport X-Ray Collimeter Specification

  • Power
  • 24V DC, 100W
  • Suitable For
  • X-ray Machines
  • Application
  • X-ray Equipment/Medical Imaging
  • Humidity Range
  • < 85% RH
  • Properties
  • Manual Light Adjustment, Smooth Movement, Fine Focus
  • Shape
  • Rectangular
  • Phase
  • Single Phase
  • Color Code
  • Black and Silver
  • Use
  • Controlling and Collimating X-Ray Beam
  • Treatment Type
  • Manual Adjustment
  • Automation Grade
  • Manual
  • Temperature Range
  • -10°C to 45°C
  • Material
  • High-grade Aluminum Alloy
  • Accuracy
  • ±1 mm
  • Product Type
  • X-Ray Collimeter
  • Dimension (L*W*H)
  • 180 x 130 x 110 mm
  • Height
  • 110 mm
  • Weight
  • Approx. 2.5 kg
  • Function
  • Beam Collimation and Field Limitation
  • Frequency
  • 50Hz
  • Power Source
  • Electric
  • Voltage
  • 220V
  • Field Indication
  • Clear with Movable Scale
  • Light Source
  • LED, 24V DC
  • Mounting
  • Universal Adaptability to X-Ray Tubes
  • Lamp Intensity Control
  • Available
  • Aperture Adjustment
  • Smooth, Linear Mechanism
  • Focal Spot Distance
  • 40-180 cm
  • Lamp Life
  • Up to 10,000 hours
  • Safety Standards
  • Complies with IEC Medical Standards


ConXport X-Ray Collimeter Trade Information

  • FOB Port
  • Delhi
  • Payment Terms
  • Paypal, Letter of Credit (L/C), Telegraphic Transfer (T/T)
  • Supply Ability
  • 15 Per Week
  • Delivery Time
  • 6-7 Days
  • Sample Available
  • Yes
  • Sample Policy
  • If order is confirmed we will reimburse the sample cost
  • Main Export Market(s)
  • Australia, North America, South America, Western Europe, Central America, Asia, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO,CE,FDA


About ConXport X-Ray Collimeter

X-Ray Collimator Is A Device That Narrows A Beam OfParticles Or Waves. To Narrow Can Mean Either To Cause The Directions Of MotionTo Become More Aligned In A Specific Direction (I.E., Make Collimated Light OrParallel Rays), Or To Cause The Spatial Cross Section Of The Beam To BecomeSmaller (Beam Limiting Device).



Advanced X-Ray Beam Collimation

The ConXport X-Ray Collimeter offers precise control over beam shape and field size in medical imaging environments. The smooth, linear mechanism enables accurate aperture adjustment, while the movable, calibrated field indicator guarantees visual clarity. Its design enhances imaging safety by confining the X-ray exposure area, supporting reliable diagnostic outcomes.


Universal Mounting and Durable Build

Designed with universal adaptability, this model fits most X-ray tubes effortlessly. The high-grade aluminum alloy body, finished in black and silver, assures both lightweight convenience and strong protection. Its compact form factor makes it suitable for a variety of X-ray machine set-ups across medical facilities.

FAQs of ConXport X-Ray Collimeter:


Q: How does the ConXport X-Ray Collimeter control the X-ray beam?

A: The collimeter utilizes a smooth, linear aperture adjustment mechanism and a fine focus system to accurately shape and limit the X-ray beam. By adjusting the movable scale, users can define the field size, ensuring precise imaging and reduced exposure to unnecessary radiation.

Q: What are the main benefits of using this collimmeter in medical imaging?

A: This device enhances diagnostic accuracy by providing clear beam limitation, minimizing patient and operator radiation exposure. Its robust, universal design and IEC-compliant safety features make it suitable for diverse medical and diagnostic environments.

Q: When should I consider replacing the LED lamp in the collimmeter?

A: The built-in LED lamp has a lifespan of up to 10,000 hours. Replacement is typically only necessary after this period or if a decline in illumination intensity is noticed during operation.

Q: Where can the ConXport X-Ray Collimeter be installed?

A: This collimmeter is universally adaptable, allowing seamless mounting on most X-ray tubes commonly used in hospitals, clinics, and diagnostic centers across India and worldwide.

Q: What is the recommended process for adjusting the aperture and field size?

A: Users can achieve the desired beam dimension by manually adjusting the smooth, linear mechanism and movable scale. The field indication system provides clear visual feedback to assist in precise alignment before taking the X-ray.

Q: How does the manual light intensity control benefit users?

A: Adjustable lamp intensity ensures optimal field visibility in various ambient lighting conditions, enhancing both operator convenience and patient safety during positioning and imaging.
