CAMERAEYEPIECE MVV-5000

Get a Price/Quote

CAMERAEYEPIECE MVV-5000 Specification

WiFi
NO

Aperture
Fixed

Feature
Lightweight, Portable, Adjustable Diopter

View Angle
Wide Field

Media Type
Digital Output via USB

Lens
Built-in Eyepiece Lens

Product Type
Microscope Camera Eyepiece

Sensor
CMOS

Features
Plug and Play, High Resolution, Software Supported

Technology
Digital

Sensor Size
1/2.8 inch Sony CMOS

ISO
Auto/Manual

Color
Black

Body Material
Aluminium Alloy

Pixels
5.0 Megapixels

Zoom Option
Digital Zoom

Battery
USB Powered

Video Capture
Yes

Video Capture Resolution
1920 x 1080

Operating System Compatibility
Windows, Mac OS

Frame Rate
Up to 30 fps

Software Included
Yes

USB Output
USB 2.0

Working Temperature
-10°C to 50°C

Mounting Type
Fits Standard Microscope Tubes (23.2mm, 30mm, 30.5mm adapters included)

Image Format
JPEG, BMP

Power Requirement
DC 5V via USB

Dimension
Approx. 80mm x 34mm

Video Format
AVI

About CAMERAEYEPIECE MVV-5000

CAMERAEYEPIECE MVV-5000

Description

Microscopedigital eyepiece camera quipped with relay lens and microscopy imaging softwareof Future Win Joe for scientific research

DigitalEyepiece camera 5.0 MP, USB 2.0

Sensor Parameter:	1/2.5 5.0MP CMOS
Resolution:	2560*1944
USB port:	USB 2.0
Frame Rate:	3.75fps for 5.0 MP
Preview Model :	25601944, 20481536,12801024 ,1024768
Pixel Size:	2.2m *2.2m
Color Filter:	RGB Bayer Pattern
White Balance:	Auto
The Length of USB:	1.5 meter
O/P compatibility:	WindowsXP2, 7 and 8
Power supply:	USB port
Tube diameter:	23.2 mm or 30.00mm
Connection:	Ocular tube or C-mount
Uniform focusing:	YES
Optical magnification:	10X
Rate of field:	1/3

Matching lens:

Yes

Function of software:

mage file management:	Set up, open up, save, lead in image file.
Image capture:	Switch, setting, shoot, measure, full screen view.
Image edit:	picture turn, zoom, cut, modify, email, print
Resolution of display:	2560*1944
Resolution of picture:	2560*1944
Resolution of video:	2560*1944
Weight of device:	0.10

Effortless Integration with Standard Microscopes

The CAMERAEYEPIECE MVV-5000 comes with adapters for 23.2mm, 30mm, and 30.5mm microscope tubes, allowing it to fit most standard models seamlessly. Instantly upgrade your microscopes imaging capabilities without complicated installation, making it perfect for quick setup in laboratories, classrooms, and professional environments.

High-Resolution Imaging for Maximum Clarity

Featuring a 1/2.8 inch Sony CMOS sensor and 5.0-megapixel resolution, this digital eyepiece delivers sharp, detailed images and smooth video at up to 30 fps. Capture vibrant visuals and wide field views, ideal for documentation, analysis, and presentation of microscopic samples.

Convenient Plug-and-Play Operation

With its USB 2.0 connection and included software, the MVV-5000 supports both Windows and Mac OS. Simply connect to your computer, and the plug-and-play design along with adjustable diopter and digital zoom ensures quick, hassle-free operationno advanced technical skills required.

FAQs of CAMERAEYEPIECE MVV-5000:

Q: How do I connect the CAMERAEYEPIECE MVV-5000 to my microscope?

A: Use one of the supplied adapters (23.2mm, 30mm, or 30.5mm) to securely fit the eyepiece into your microscopes standard tube. Then, connect the device to your computer using the provided USB 2.0 cable.

Q: What operating systems are compatible with the MVV-5000?

A: The CAMERAEYEPIECE MVV-5000 is compatible with both Windows and Mac OS, ensuring flexibility across different computer platforms.

Q: When is the best time to use the digital eyepieces high-resolution video capture feature?

A: High-resolution video capture is ideal for real-time demonstration, documentation, and recording of live microscopic events, making it valuable during lab work, teaching, or presentations.

Q: Where can I save the images and videos captured with this eyepiece?

A: Captured JPEG, BMP images, and AVI videos are saved directly onto your connected computer, allowing easy access, editing, and sharing of your microscopy findings.

Q: What is the process for setting up and powering the MVV-5000?

A: Simply insert the eyepiece with the appropriate adapter into your microscope, connect it to your computer via USB (which supplies DC 5V power), and install the included software to start capturing images and videos.

Q: How does using the MVV-5000 benefit my microscopy workflow?

A: By upgrading your microscope with high-resolution digital imaging, you gain the ability to easily document and share results, improve collaboration, and simplify the analysis process. The portable, lightweight design also makes it suitable for fieldwork.

Q: What mounting options does the eyepiece provide?

A: The MVV-5000 supports standard microscope tube sizes with included adapters (23.2mm, 30mm, 30.5mm), ensuring a customized, secure fit for a broad range of microscope models.
