MVV- 1300 CAMERA EYEPIECE

MVV- 1300 CAMERA EYEPIECE About

CAMERA EYEPIECE

Description

Microscopedigital eyepiece camera quipped with relay lens and microscopy imaging softwareof Future Win Joe for scientific research

DigitalEyepiece camera 1.3 MP, USB 2.0

Sensor Parameter:	1/2 1.3MP CMOS
Resolution:	1280*1024
USB port:	USB 2.0, 480 MB /s
Frame Rate:	16 f/s @ 1280*1024
Preview Model :	1280*1024, 640*480, 320*240
Pixel Size:	5.2m *5.2m
Sensitivity:	1.8 V/lux-sec@550nm
Spectrum response:	400nm1000nm
Shutter Type:	White ERS(electronic rolling shutter)
Balance:	Auto
The Length of USB:	1.5 meter
O/P compatibility:	WindowsXP2, 7 and 8
Power supply:	USB port
Tube diameter:	23.2 mm or 30.00mm
Connection:	Ocular tube or C-mount

Versatile Compatibility

Effortlessly adaptable to most standard microscopes thanks to its 23 mm mounting diameter and supplied adapters for 30 mm and 30.5 mm tubes, the MVV-1300 Camera Eyepiece offers seamless integration. This wide compatibility ensures users can easily mount the device on various microscope models without the need for additional equipment.


High-Resolution Imaging

Capture vivid and detailed images or video with the MVV-1300s 3.2 MP CMOS sensor, supporting crisp resolutions up to 2048 x 1536 pixels. The integrated digital eyepiece lens ensures accurate representation of your microscopic observations for research, documentation, or educational demonstrations.


User-Friendly Operation

The MVV-1300 is straightforward to connect and use, featuring plug-and-play functionality with a standard USB 2.0 interface. Its software is compatible with multiple Windows versions, allowing swift installation and hassle-free operation in classrooms, labs, or industrial environments.
