ConXport Rocking Microtome
ConXport Rocking Microtome

ConXport Rocking Microtome

ConXport Rocking Microtome Specification

  • Treatment Type
  • Histology and Pathology Studies
  • Accuracy
  • 0.001 mm (1 micron) section thickness
  • Phase
  • Single Phase
  • Dimension (L*W*H)
  • Approx. 290 x 210 x 230 mm
  • Shape
  • Rectangular Base with Rocker Mechanism
  • Power
  • Manual operation (No electric power required)
  • Properties
  • High precision with sturdy construction
  • Product Type
  • Rocking Microtome
  • Color Code
  • Hammer Tone Blue-Grey
  • Weight
  • 11.5 kg (Approx.)
  • Automation Grade
  • Manual
  • Use
  • Used in histology and pathology laboratories
  • Application
  • Cutting thin sections of biological specimens
  • Height
  • 230 mm (approx.)
  • Suitable For
  • Medical and biological research institutes
  • Material
  • Cast Iron and Steel Components
  • Function
  • Sectioning biological tissues into microns
  • Power Source
  • Manual
  • Knife Size
  • 120 mm (l) x 20 mm (w)
  • Movement
  • Rocking Mechanism for Specimen feed
  • Mounting
  • Supplied with wooden storing case
  • Operating System
  • Hand-operated
  • Specimen Feed Adjustment
  • Micrometer Screw with Vernier Scale
  • Included Accessories
  • Razor with back and handle, honing plate, oil can, dust cover, object holders
  • Section Thickness Range
  • 2 24 microns (adjustable)
  • Cutting Capacity
  • Up to 2 mm thickness specimen
  • Knife Material
  • High Carbon Steel


ConXport Rocking Microtome Trade Information

  • FOB Port
  • Delhi
  • Payment Terms
  • Letter of Credit (L/C), Telegraphic Transfer (T/T), Paypal
  • Supply Ability
  • 15 Per Week
  • Delivery Time
  • 6-7 Days
  • Sample Available
  • Yes
  • Sample Policy
  • If order is confirmed we will reimburse the sample cost
  • Main Export Market(s)
  • Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO,CE,FDA,WHO-GMP


ConXport Rocking Microtome About

Cambridge RockingMicrotome is very well known and one of the best established microtomes in theworld, which has given outstanding service to numerous microtomists through theyears. It is designed for sectioning comparatively soft, wax-embedded tissueswith a thickness range of 2 m to 24 m, in steps of 2 m. Calibrated in 2micron divisions, the section cutting thickness can be set easily and quicklyby a single control. It is recommended for elementary biology & pathologystudents.
The rocking microtome is an extremely reliable instrument comprising of threemoving parts. The lead screw mechanism incorporates quality precisionengineering and the cutting stroke is controlled by a single control leverwhich minimizes the operator skill required. It carries wide choice of specimenholders cylindrical holders, standard orientating & wood block holders forsectioning wax embedded specimens.



Precise Sectioning for Enhanced Research

This microtome excels in producing uniform thin sections, which are essential for detailed microscopic analysis. Its micrometer screw and Vernier scale system ensure accuracy, while the sturdy hand-operated rocker mechanism gives users meticulous control over cutting. With section thickness adjustable between 2 and 24 microns, researchers can customize their samples to fit a variety of investigative protocols.


Durable Construction and Thoughtful Accessories

Built with cast iron and steel components, the ConXport Rocking Microtome offers enduring performance. The included accessories, such as a knife with back and handle, honing plate, oil can, and dust cover, streamline the sectioning workflow. The supplied wooden case aids in safe storage, making it convenient for busy laboratory environments.


Manual Operation for Reliable Performance

Designed for manual operation, this microtome requires no electric power or complex controls, thus reducing maintenance demands. Its rocker mechanism and easy-to-use adjustment features make it suitable for laboratories prioritizing consistency and straightforward operation, especially in locations where electric-powered equipment may not be practical.

FAQs of ConXport Rocking Microtome:


Q: How does the ConXport Rocking Microtome achieve precise section thickness?

A: The microtome uses a micrometer screw with a Vernier scale, enabling highly accurate specimen feed adjustment. This ensures section thickness can be finely tuned between 2 and 24 microns, with a precision of up to 1 micron, making it ideal for detailed histological studies.

Q: What is the main benefit of the rocking mechanism in this microtome?

A: The rocking mechanism provides smooth, controlled feed movement, ensuring consistent slice thickness and minimizing specimen damage. Its especially beneficial for producing thin, uniform tissue sections for microscopic examination.

Q: When is the ConXport Rocking Microtome most suitable for use?

A: This microtome is best utilized in histology and pathology laboratories when preparing biological specimens for slide analysis. Its manual operation makes it especially useful in settings without reliable access to electric power.

Q: Where can the ConXport Rocking Microtome be effectively employed?

A: It is commonly used in medical and biological research institutes, particularly within histology and pathology labs, due to its precision and sturdy construction. Its portability and manual operation make it suitable for a variety of laboratory environments.

Q: What accessories are included with the ConXport Rocking Microtome?

A: The microtome comes complete with a razor outfitted with back and handle, honing plate, oil can, dust cover, and object holders. These accessories facilitate specimen preparation and maintenance, ensuring reliable performance and convenience.

Q: How is specimen feed adjustment performed in this microtome?

A: Specimen feed adjustment is controlled via a micrometer screw combined with a Vernier scale, allowing users to precisely regulate the advance of the specimen for each cut, thus ensuring accurate sectioning according to requirements.
