ConXport . Slit Lamp Five Step

Get a Price/Quote

ConXport . Slit Lamp Five Step Specification

Voltage
100-240V AC

Automation Grade
Manual

Power Source
Electric

Frequency
50/60 Hz

Feature
Five-Step Magnification, LED Illumination

Accuracy
High Precision Optical System

Core Components
Eyepiece, Objective Lens, Illumination System

Model No
ConXport Slit Lamp Five Step

Equipment Materials
High-quality Metal and Optical Glass

Type
Five Step Slit Lamp

Usage
Ophthalmic Examination

Display Type
Binocular

Dimension (L*W*H)
Approx. 600 x 360 x 850 mm

Weight
Approx. 12 kg

Working Distance
100 mm

Chinrest Adjustment
85 mm

Pupil Distance Adjustment
52 75 mm

Slit Width
0-14 mm continuous

Magnification Steps
5 (6.3x, 10x, 16x, 25x, 40x)

Base Travel
105 mm (longitudinal), 110 mm (lateral), 30 mm (vertical)

Slit Rotation
0 180

Light Source
LED Lamp 3V/5W

Slit Length
1-14 mm continuous

Illumination Type
LED

Operating Temperature
10C to 40C

Filters Provided
Heat Absorbing, Red-Free, Cobalt Blue, Neutral Density

Relative Humidity
85%

Eyepiece
12.5x Widefield

ConXport . Slit Lamp Five Step Trade Information

FOB Port
Delhi

Payment Terms
Letter of Credit (L/C), Telegraphic Transfer (T/T), Paypal

Supply Ability
15 Per Week

Delivery Time
6-7 Days

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Australia, North America, Eastern Europe, Western Europe, Middle East, Central America, South America, Asia, Africa

Main Domestic Market
All India

Certifications
ISO,CE,FDA,WHO-GMP

ConXport . Slit Lamp Five Step About

Discover an unprecedented blend of pristine optics and robust engineering with the ConXport Slit Lamp Five Step, the new release setting a classic benchmark for ophthalmic examinations. Find five distinctive magnification steps (6.3x, 10x, 16x, 25x, 40x) and redeem enhanced clinical clarity through widefield 12.5x eyepieces and precise LED illumination. Crafted from high-quality metal and optical glass, this manual Galilean slit lamp offers continuous slit width and length adjustments, multiple essential filters, and ergonomic controlsdelivering high precision for comprehensive ocular evaluations.

Why Choose ConXport Slit Lamp Five Step?

Enjoy primary competitive advantages such as superior optical clarity, durable construction, and versatile adjustment options. With continuous slit width and length settings, practitioners achieve accurate diagnosis every time. The ergonomic design enables comfortable and precise operation, while LED technology ensures consistent, brilliant illumination. For best results, set the pupil distance to match each patient, adjust slit parameters using the intuitive controls, and utilize the integrated filters as needed. ConXports advanced optics make it a superior choice for modern clinics.

Delivery Details & Commercial Information

Benefit from our streamlined outlay process for the ConXport Slit Lamp Five Step, with estimate delivery times provided upon proposal acceptance. Our products are typically dispatched from major Indian FOB ports and meet relevant quality certifications to ensure excellence in every shipment. When you request a proposal amount, our team provides detailed estimates for accurate business planning. Timely fulfillment, certified reliability, and seamless logistics define the ConXport commitment to customer satisfaction.

Slit Lamp Five Step

Microscope	Galilean
Magnification	3 Step: 10X, 16X, 25X Optional: 5 Step
Eyepieces	Wf 12.5X/18Mm, Diopter Adj. 5Mm
IP Range	48.5-77Mm
Slit Length/Width	0-13.5 Mm
Slit Apertures	0.6, 5.8,9,13.5Mm And Continous 1.5 To 12.0Mm
Slit Rotation	0-180Degree
Filters	Red Free, Cobalt Blue, Heat Absorbing
Longitudinal(In/Out)	100Mm
Lateral(Left/Right)	107Mm
Vertical(Up/Down)	30Mm
Chin Rest Range	80Mm
Illumination	6V 20W Halogen
Table Base Size	465Mm X 316Mm
Weight	25Kg (Packed)
Optional Accessories	Tonometer, Beam Splitter, Ccd, Diffuser Motorized Table

FAQs of ConXport . Slit Lamp Five Step:

Q: How does the five-step magnification system improve ophthalmic examinations?

A: The five-step magnification system (6.3x, 10x, 16x, 25x, 40x) allows practitioners to adjust and find optimal levels of detail during eye assessments, ensuring both overview and minute inspection with pristine optical quality.

Q: What are the main benefits of the LED illumination system?

A: LED illumination provides bright, consistent, and energy-efficient lighting, enhancing visualization of ocular structures while maintaining low heat output for improved patient comfort during examinations.

Q: Where is the ConXport Slit Lamp Five Step typically used?

A: This equipment is ideal for ophthalmology clinics, research institutions, and hospitals where high-precision anterior and posterior eye segment examination is required.

Q: What filters are included and how do they support diagnostics?

A: The lamp includes heat absorbing, red-free, cobalt blue, and neutral density filters. These filters enable tailored light conditions, aiding in detailed corneal, retinal, and vascular assessments.

Q: How should the slit lamp be maintained for optimal performance?

A: Regularly clean the optical glass surfaces with proper lens cleaning solutions, check LED lamp functionality, and ensure that all moving parts are kept dust-free for uninterrupted and accurate performance.
